Pepperl+Fuchs S1SD-1AI-2C Transmitter Power Supply / Signal Splitter, 1-Channel, 24 V DC, Dual 0/4–20 mA Outputs

The S1SD-1AI-2C belongs to the Pepperl+Fuchs SC-System of compact signal conditioners. It supplies a connected 2-wire transmitter and receives a 0/4–20 mA input signal. The signal is then made available at two separate current outputs, making the module suitable for feeding the same process measurement to two independent control or monitoring systems.

It provides 24 V DC transmitter supply, galvanic isolation between field and control circuits, and converts one input signal into two isolated 0/4–20 mA outputs. It is designed for DIN-rail mounting and offers 0.1% accuracy.

The device provides reinforced galvanic isolation between the input, outputs and power supply, with a rated insulation voltage of 300 V and a test voltage of 3 kV. Its compact 6.2 mm-wide housing allows high-density installation on 35 mm DIN rails.

Key Features

• 1-channel signal conditioner
• Transmitter power supply
• Signal splitter
• Designed for 2-wire transmitters
• 24 V DC supply
• 1 × analog current input
• 2 × analog current outputs
• Input/output range: 0/4–20 mA
• Accuracy: 0.1% of full-scale value
• Galvanic isolation
• 300 V rated insulation voltage
• 3 kV test voltage
• DIN-rail mounting
• Compact 6.2 mm housing width
• IP20 protection
• Extended operating temperature: -25 to +70°C
• ATEX and IECEx-related hazardous-area approvals

Main Applications

• Industrial process instrumentation
• Analog signal isolation
• 4–20 mA signal splitting
• PLC analog input systems
• DCS systems
• Process control
• Pressure/temperature/flow transmitter interfaces
• Chemical and petrochemical plants
• Factory automation
• Hazardous-area instrumentation

Product Status: Active / Current
