IC693DSM302 GE Fanuc 90-30 Programmable Coprocessor Module

Product parameters

I/O points: 16 digital input points + 16 digital output points (total 32 points).

Input characteristics:

Type: DC input (source type/drain type compatible, can be switched via jumper).

Voltage range: 10 to 30VDC (typical 24VDC).

Input current: approximately 7mA when on, ≤1mA when off.

Response time: ≤10ms (on/off).

Output characteristics

Type: Transistor output (NPN drain type).

Voltage range: 10 to 30VDC (typical 24VDC).

Output current: Maximum 0.5A per point, maximum total current of 2A per group of 8 points, maximum total current of 4A per module.

Switching frequency: ≤1kHz (resistive load).

Isolation and Protection

Photoelectric isolation (isolation voltage 2500V AC) is adopted between the input, output and backplane bus.

The output is equipped with self-recovering short-circuit protection and will automatically recover after the fault is eliminated.

Environment and Installation

Operating temperature: 0℃ to 60℃ Storage temperature: -40℃ to 85℃.

Protection grade: IP20 (To be installed in the control cabinet).

Function

Hybrid I/O integration: A single module integrates 16 inputs and 16 outputs, reducing the number of modules and saving control cabinet space. It is suitable for small and medium-sized equipment with concentrated I/O points.

Flexible adaptation: The input supports source type/drain type switching and is compatible with NPN or PNP sensors (such as proximity switches, photoelectric switches). The transistor output can directly drive small solenoid valves, indicator lights, relay coils and other DC loads.

Anti-interference and protection: The photoelectric isolation design isolates external circuit interference, enhancing system stability. Output short-circuit protection prevents the module from being damaged due to load faults.

Status visualization: Each point is equipped with an LED indicator light to display the input/output on/off status in real time, facilitating rapid debugging and fault location.

Application scenarios

Small-scale automated equipment: such as packaging machines, labeling machines, and small assembly machines, synchronously collect sensor signals (such as workpiece positioning and limit detection) and control actuating elements (such as solenoid valves and cylinder actions).

Production line workstation control: Integrate control logic in a single workstation, such as the start and stop (output) and position detection (input) of motors for material conveying, as well as the clamping/releasing control of tooling fixtures.

Warehousing and logistics equipment: such as small conveyor belts, sorting mechanisms, control drive components (output) and receive signals from photoelectric sensors and limit switches (input).

Equipment renovation and upgrade: It is used for I/O expansion of 90-30 PLC systems, supplementing points while simplifying wiring and reducing the complexity of renovation.
