IC693MDL340 GE Fanuc 90-30 Discrete I/O Module

Core parameters

Input points: 32 channels, DC input type (divided into 2 groups, 16 channels in each group)

Rated input voltage: DC 24V (Compatible with a wide range of DC 10 to 30V, suitable for multiple sensor specifications)

Signal threshold

Signal "0" (OFF) : ≤5V DC

Signal "1" (ON) : ≥10V DC

Input current: Typical value per channel is 7mA (at 24V), maximum 10mA

Input delay: Default ≤1ms (Supports external filtering adjustment to handle high-frequency interference scenarios)

Isolation method: Electrical isolation between groups (each group is also isolated from the backplane bus), isolation voltage 1500V AC (1 minute)

Working environment: Working temperature 0~60℃, storage temperature -40 ~+85℃. Humidity: 5% to 95% (non-condensing)

Power consumption: The maximum backplane bus current is 50mA (5V DC), and no external independent power supply is required

Function

High channel density: 32-channel design, compared with 16-channel modules of the same series (such as IC693MDL310), can reduce the number of modules, lower system integration costs, and be suitable for multi-signal acquisition scenarios.

Inter-group isolation protection: Two groups of channels are independently isolated. When one group of signals fails (such as short circuit or overvoltage), it does not affect the other group. At the same time, external interference is isolated to enhance the stability of signal acquisition.

Wide voltage and fast response: Compatible with DC 10~30V input, it can be connected to different brands of DC 24V sensors (such as photoelectric switches, proximity switches); A delay of ≤1ms can quickly capture high-speed switching signals (such as workpiece inspection on assembly lines).

Seamless integration: Specifically designed for the MicroLogix 1000/1100/1200 series PLCS, it is plug-and-play via the backplane bus, automatically allocates addresses, supports Rockwell RSLogix programming software, and is easy to debug.

Application scenarios

Medium-sized production line signal acquisition: such as electronic component assembly lines and food packaging lines, connect up to 32 DC 24V limit switches and photoelectric sensors to monitor the status of multi-station equipment (such as workpiece placement, conveyor belt start and stop).

Equipment cluster status monitoring: Signals such as emergency stop buttons, safety door switches, and cylinder position feedback from multiple single machines (such as punch presses, welding machines, and injection molding machines) in small workshops are aggregated and collected, and then uploaded centrally to the PLC host.

Logistics sorting system: In small sorting lines and stereoscopic warehouses, it collects signals from photoelectric beam sensors and encoders at multiple storage locations to achieve material positioning and counting.

Automation transformation project: When installing PLC control for traditional multi-station equipment (such as old textile machines and printing machines), it serves as an input expansion module to achieve multi-signal digital upgrade at a low cost.

Advantage Products:

All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.

Many Available just wait for you, feel free to ask to get better deal!!!
