OMRON R88L-EC-GW-0503-ANPS IRONLESS MOTOR COIL UNIT G5 SERIES

Product parameters

Type: Ironless Motor Coil Unit (Ironless Motor Coil)

Model: R88L-EC-GW-0503-ANPS

Rated force: 58 N

Instantaneous maximum force: 240 N

Magnetic track width: 50mm

Coil number: 3 coils

Connector: No connector

Compatible drivers: R88D-KN01H-ECT-L (100 W, single-phase/three-phase 200 VAC) and other G5 series drivers

Environmental conditions: Operating temperature: 0 to 40°C

Operating humidity: Maximum 85% RH (no condensation)

Storage temperature: -20 to 60°C

Storage humidity: Maximum 85% RH (no condensation)

Operating environment: No corrosive gases

Protection grade: IP00 (Open structure, protection required according to the application environment)

Coil temperature: The rated value is based on a 100°C coil temperature and a 25°C magnetic rail temperature

Certification standards: EMC: EN 55011, EN 61000-6-2, EN 61800-3

Low voltage: EN 61800-5-1

Mechanical safety: EN 954-1 (Cat.3), EN ISO 13849-1 (PLc,d), EN 61508 (SIL2), EN 62061 (SIL2), EN 61800-5-2 (STO)

UL: UL 508C

CSA: CSA C22.2 No.14

Korean Radio Regulations (KC) : Certified

Function

Coreless design: Compared with coreless types, coreless motors have lower thrust fluctuations and a higher force-to-weight ratio, making them suitable for applications that require smooth motion

High dynamic performance: Rated force 58 N, instantaneous maximum force 240 N, suitable for high-precision and low-thrust applications

EtherCAT communication compatibility: Combined with the R88D-KN01H-ECT-L driver, it supports cyclic synchronous position, speed and torque modes, as well as return and probe functions, achieving real-time high-precision control

Modular design: The connectionless design facilitates customized cable configuration, is compatible with various magnetic track lengths, and offers high flexibility

Temperature management: Built-in temperature sensor support, external cooling (2.5m /s airflow) is required to maintain performance

Safety features: Supports safe torque turn-off (STO) through the driver, in compliance with EN 61800-5-2 standard

High-resolution feedback: Supports 20-bit high-resolution encoders, providing outstanding positioning accuracy

Application scenarios

Semiconductor manufacturing: Used in high-precision linear motion scenarios such as wafer handling and chip positioning that require extremely low thrust fluctuations

Medical equipment: Provides smooth and precise linear drive in precision medical instruments such as imaging equipment

Precision testing equipment: used for test platforms that require high repeatability and precise positioning, such as optical inspection equipment

Automated production lines: Achieving precise linear motion in high-speed assembly lines or small handling systems

Electronic assembly: Suitable for SMT equipment, surface mount technology (SMT) placement machines and other scenarios that require high dynamic response and low vibration

Laboratory automation: Provide smooth and high-precision motion control in laboratory robots or automated experimental equipment

Advantage Products:

All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.

Many Available just wait for you, feel free to ask to get better deal!!!
