OMRON R88L-EC-FW-0306-ANPC IRON-CORE MOTOR COIL UNIT G5 SERIES

Product parameters

Type: Iron-core Motor Coil unit

Model: R88L-EC-FW-0306-ANPC

Rated force: 96 N

Instantaneous maximum force: 210 N

Magnetic track width: 30mm

Coil number: 6 coils

Connector: No connector

Compatible drivers: R88D-KN01H-ECT-L (100 W, single-phase/three-phase 200 VAC) and other G5 series drivers

Environmental conditions: Operating temperature: 0 to 40°C (It is necessary to ensure that the temperature rise rate of the coil is controlled within 6K/s. It is recommended to apply a 25°C air flow cooling of 2.5m /s)

Operating humidity: Maximum 85% RH (no condensation)

Storage temperature: -20 to 60°C

Storage humidity: Maximum 85% RH (no condensation)

Operating environment: No corrosive gases

Protection grade: IP00 (Open structure, protection required according to the application environment)

Coil temperature: The rated value is based on a 100°C coil temperature and a 25°C magnetic rail temperature

Certification standards: EMC: EN 55011, EN 61000-6-2, EN 61800-3

Low voltage: EN 61800-5-1

Mechanical safety: EN 954-1 (Cat.3), EN ISO 13849-1 (PLc,d), EN 61508 (SIL2), EN 62061 (SIL2), EN 61800-5-2 (STO)

UL: UL 508C

CSA: CSA C22.2 No.14

Korean Radio Regulations (KC) : Certified

Function

High-efficiency core design: It offers high-speed and high duty cycle operation, making it suitable for applications requiring high thrust

EtherCAT communication compatibility: Combined with the R88D-KN01H-ECT-L driver, it supports cyclic synchronous position, speed and torque modes, as well as return and probe functions, achieving real-time high-precision control

High dynamic performance: Rated force 96 N, instantaneous maximum force 210 N, suitable for rapid response and heavy-duty applications.

Modular design: The connectionless design facilitates customized cable configuration and is compatible with various magnetic track lengths (96mm, 144mm, 384mm), offering high flexibility

Temperature management: Built-in temperature sensor support, external cooling (2.5m /s airflow) is required to maintain performance

Safety features: Supports safe torque turn-off (STO) through the driver, in compliance with EN 61800-5-2 standard

Application scenarios

Semiconductor manufacturing: used in high-precision linear motion scenarios such as wafer handling and chip positioning.

Automated production lines: Provide precise linear drive in high-speed assembly lines or conveyor belt systems.

Packaging machinery: Achieve rapid and smooth motion control of packaging equipment.

Precision processing: such as laser cutting or CNC equipment, to meet the demands of high thrust and high precision.

Robotics technology: Used for linear joint drive, providing high dynamic response and stability.

Test equipment: Applied in test platforms that require high repeatability and precise positioning.
