OMRON R88D-KN01H-ECT-L AC SERVO MOTOR G5 SERIES

Product parameters

Servo control mode: EtherCAT

Rated output power: 100 W

Input power supply: Main circuit: Power capacity: 0.5 KVA

Power supply voltage: Single-phase or three-phase 200-240 VAC (170-264 V), 50/60 Hz

Rated current: 1.6A (single-phase) / 0.9A (three-phase)

Calorific value: 14.3W (single-phase) / 13.7W (three-phase)

Control circuit: Power supply voltage: Single-phase 200-240 VAC (170-264 V), 50/60 Hz

Calorific value: 4 W

Output current: Continuous output current (RMS) : 1.2A

Maximum motor current: 3.6 Arms

Environmental conditions: Operating temperature: 0 to 55°C

Operating humidity: Maximum 85% RH (no condensation)

Storage temperature: -20 to 65°C

Storage humidity: Maximum 85% RH (no condensation)

Operating environment: No corrosive gases

Vibration resistance: 10 to 60 Hz, maximum acceleration 5.88 m/s²

Impact resistance: Maximum acceleration 19.6 m/s², twice each in the X, Y, and Z directions

Insulation resistance: ≥ 0.5M Ω (500 VDC) between the power supply/power line terminal and the frame ground

Dielectric strength: Between the power supply/power line terminal and the frame ground, 1500 VAC, 1 minute (50/60 Hz)

Protection grade: Built into the panel

International standards: EMC: EN 55011, EN 61000-6-2, EN 61800-3

Low voltage: EN 61800-5-1

UL standard: UL 508C

CSA standard: CSA C22.2 No.14

Korean Radio Regulations (KC) : Certified

Installation method: Chassis Mount

Function

EtherCAT communication: Supports IEC 61158 Type 12 and IEC 61800-7 CiA 402 drive profiles, 100BASE-TX physical layer, RJ45×2 connectors (ECAT IN/OUT), enabling fast and real-time data exchange.

Control mode: Cyclic synchronous position mode

Loop synchronous speed mode

Cyclic synchronous torque mode

Contour position pattern

Return mode

Touch detection function (latch function

Torque limiting function

Distributed Clock (DC) : Supports 250 μs, 500 μs, 1 ms, 2 ms, and 4 ms synchronization cycles.

Compatibility: Compatible with R88M-K series 3000 r/min servo motors (such as R88M-K05030H/T, R88M-K10030H/T, with incremental or absolute encoders, with or without brakes) or R88L-EC series linear motors.

Safety features: Built-in safety torque turn-off (STO), in compliance with EN 61800-5-2.

Interface: EtherCAT and USB interfaces for easy configuration and debugging.

High-precision control: Supports high-resolution feedback encoders (motor specifications need to be confirmed) to ensure precise positioning and motion control.

Application scenarios

Industrial automation: Used in CNC machine tools and automated production lines to perform high-precision positioning tasks.

Robot technology: Applicable to robot joint drive, meeting the requirements of high response speed and stability.

Semiconductor manufacturing: Providing high-precision control in wafer handling and precision positioning equipment.

Packaging machinery: Achieve rapid and smooth motion control of packaging equipment.

Material handling: Used in conveyor belts and automated handling systems to ensure efficient and stable operation.

Printing equipment: Supports high-speed and precise motion control of printing machines.
