IC693CSE311 GE Fanuc 90-30 CPU Base

Product parameters

Communication protocol: Supports PROFIBUS-DP V1 protocol, compatible with DP slave/master mode (default slave, master can be configured through configuration)

Communication rate: Adaptive 9.6kbps to 12Mbps, supports manual rate configuration to meet different distance and real-time requirements

Interface type: 1 PROFIBUS-DP standard interface (RS-485 physical layer), with shielded terminals and anti-interference design

Bus connection: Supports bus topology, capable of connecting up to 125 DP slave stations (in master station mode)

Electrical isolation: Electrical isolation is achieved between the communication interface and the PLC backplane bus, with an isolation voltage of ≥500V AC. The anti-electromagnetic interference (EMC) complies with the EN 55011/EN 55022 standards

Power supply parameters: Powered by the backplane bus of Series 90-30 PLC, the working voltage is DC 5V, and the typical power consumption is approximately 2.5W

Working environment: Working temperature 0℃ to 60℃, storage temperature -40 ℃ to 85℃. Relative humidity 5% to 95% (no condensation)

Mechanical characteristics: Compatible with Series 90-30 standard 35mm DIN rail installation, module width approximately 32mm, wiring with front connector (recommended GE Fanuc IC693CBL300 series cable)

Configuration software: Supports configuration with GE Fanuc VersaPro and Concept software, and is compatible with third-party simulation tools such as S7-PLCSIM

Diagnostic function: Integrated power supply and communication status indicator lights (PWR, COM, ERR), supporting feedback of diagnostic information such as bus faults and slave station offline

Function

PROFIBUS-DP network access: As a communication expansion module for Series 90-30 PLC, it realizes bidirectional data interaction between PLC and PROFIBUS-DP network, supports master mode (controlling DP slave stations) or slave mode (controlled by the superior master station), and is compatible with distributed control architecture

High-speed data transmission: With a maximum communication rate of 12 Mbps, it meets the real-time control requirements of industry, capable of quickly transmitting switch quantity, analog quantity data and equipment control instructions, featuring low latency and strong stability

Multi-slave station expansion capability: In master station mode, up to 125 DP slave stations (such as digital I/O modules, analog modules, frequency converters, sensors, etc.) can be connected, supporting flexible configuration of slave station addresses to expand the PLC control range

Electrical isolation and anti-interference: The isolation design between the communication interface and the backplane bus effectively blocks electromagnetic interference and voltage fluctuations in industrial sites, ensuring the stable operation of communication links and PLC systems

Convenient diagnosis and maintenance: The power supply, communication status and fault information are intuitively fed back through status indicator lights. Combined with configuration software, detailed diagnostic data can be read to quickly locate bus faults, slave station offline and other issues, reducing maintenance costs

Seamless system integration: Seamlessly compatible with the backplane bus of Series 90-30 PLC, no additional wiring is required. Data interaction can be achieved after configuration. It supports communication with the upper computer (such as SCADA, HMI) through the PROFIBUS-DP network to achieve centralized monitoring

Application scenarios

Distributed automated production line In automotive parts assembly lines and electronic component production lines, as the PROFIBUS-DP master station interface of Series 90-30 PLC, it connects distributed I/O modules (such as remote digital output modules, analog acquisition modules), frequency converters, servo drivers and other devices to achieve multi-station collaborative control

Process industry communication networking: In the chemical, petroleum and pharmaceutical industries, the Series 90-30 PLC is connected to the PROFIBUS-DP network to communicate with on-site transmitters, valve actuators, pump set controllers and other equipment, achieving process parameter collection and remote control of equipment, and adapting to the decentralized layout of large factory areas

Networking of intelligent manufacturing equipment: In CNC machine tools and robot workstations, it serves as a communication bridge between PLC and PROFIBUS-DP slave devices (such as robot controllers and machine tool auxiliary modules), achieving action coordination and data interaction among devices (such as synchronizing the robot's material picking and placing with the machine tool's processing rhythm)

Energy and infrastructure monitoring: In substations and water treatment plants, the Series 90-30 PLC is connected to the PROFIBUS-DP network to communicate with high-voltage switch controllers, flow meters, water pump frequency converters and other equipment, achieving equipment status monitoring and remote start-stop control to ensure the stable operation of the system

In the metallurgical and building materials industry: In the sintering production lines of steel mills and the batching systems of cement plants, this module is used to network PLCS with distributed weighing modules, belt conveyor frequency converters, valve actuators and other equipment, achieving real-time adjustment of production process parameters and equipment linkage

Upgrading and transformation of the old system: For the old production line adopting Series 90-30 PLC, the PROFIBUS-DP communication function can be expanded through this module. The new DP slave station equipment can be connected without replacing the PLC body, achieving system function upgrading and expansion and reducing the transformation cost
