Beckhoff EP3174-0002 EtherCAT Box 4-Channel Analog Input Module, ±10 V / 0/4–20 mA, 16-bit, Differential, M12

Each of its four analog input channels can be independently parameterized for standard voltage or current signals. Supported signal ranges include -10…+10 V, 0…10 V, 0…20 mA and 4…20 mA. The module digitizes the input signals with a 16-bit resolution and transmits the measured values to the higher-level controller via the EtherCAT fieldbus.

The four channels are differential inputs and use individual 5-pin M12 connectors. The module supports configurable input filtering, signal scaling and automatic limit-value monitoring. The configurable input filter can operate up to a cutoff frequency of 5 kHz, while the typical conversion time is approximately 100 µs.

The EP3174-0002 is housed in a compact PA6 polyamide industrial enclosure and provides IP65/IP66/IP67 protection, making it suitable for decentralized installation close to sensors and measuring equipment without requiring a conventional control cabinet installation.

Main Features

• 4 analog input channels
• Differential analog inputs
• Individually parameterizable channels
• Supports voltage and current signals
• -10…+10 V
• 0…10 V
• 0…20 mA
• 4…20 mA
• 16-bit resolution
• Approximately 100 µs conversion time
• Configurable input filter
• Input filter cutoff frequency up to 5 kHz
• Automatic limit monitoring
• Signal scaling
• EtherCAT communication
• Distributed Clocks supported
• 500 V electrical isolation
• M12 signal connectors
• Compact field-mounted EtherCAT Box
• IP65/IP66/IP67 protection
• Operating temperature -25…+60 °C
• CE, CCC, UL, ATEX and IECEx approvals/markings

Application Scope

The EP3174-0002 is suitable for:

• Industrial automation systems
• PLC-based control systems
• Process automation
• Factory automation
• Sensor signal acquisition
• Pressure, flow and temperature measurement systems
• Analog transmitter monitoring
• Industrial measurement systems
• Machine automation
• Decentralized I/O architectures
• Remote analog signal acquisition
• Field-mounted EtherCAT systems
• Process instrumentation

Typical applications include connecting 0/4–20 mA transmitters and ±10 V / 0–10 V sensors directly to an EtherCAT-based control system.
