Beckhoff EP2028-0032 EtherCAT Box 8-Channel Digital Output 24 V DC 2.8 A M12

The Beckhoff EP2028-0032 EtherCAT Box is an 8-channel digital output module designed for decentralized control of actuators in industrial automation systems.

The module receives output commands from an EtherCAT master/controller and switches the corresponding 24 V DC control signals to field-level loads. The eight outputs can control resistive, inductive and lamp loads, with each channel supporting up to 2.8 A. The combined current of all eight outputs must not exceed 16 A at 40 °C.

Each output is individually short-circuit protected. The typical short-circuit current is approximately 15 A, and the typical switching time is approximately 200 µs for both turn-on and turn-off.

The EP2028-0032 provides two EtherCAT M8 interfaces for EtherCAT input and downstream connection. The power section uses separate 7/8-inch, 5-pin connectors for power input and downstream power forwarding. The logic/control supply and output/load supply are electrically isolated, with 500 V electrical isolation specified for the module.

The M12 output arrangement also provides flexible actuator wiring. Beckhoff documentation states that two digital outputs are available across adjacent M12 sockets, allowing either separate cables for individual actuators or a common cable arrangement for two actuators.

Main Features

• 8 digital outputs
• 24 V DC output voltage
• 2.8 A maximum per output
• 16 A maximum total output current
• Individual short-circuit protection
• Short-term overload capability
• Suitable for resistive loads
• Suitable for inductive loads
• Suitable for lamp loads
• Typical switching time: 200 µs ON / 200 µs OFF
• 2 × M8 EtherCAT interfaces
• 8 × M12 output connections
• 5-pin A-coded M12 connectors
• 7/8-inch power supply connectors
• LED output status indication
• 500 V electrical isolation
• IP65/IP66/IP67 protection
• PA6 polyamide housing
• Interference-free output behavior
• Suitable for decentralized field installation
• CE marking
• UL approval/marking in preparation according to the current product page

Application Scope

The EP2028-0032 is suitable for:

• Industrial automation
• Machine automation
• Factory automation
• PLC-controlled actuator systems
• Conveyor systems
• Motor and valve control
• Solenoid valve control
• Contactors and relays
• Signal lamps
• Industrial actuators
• Decentralized EtherCAT I/O systems
• Field-level output control
• Process automation
• TwinSAFE-related applications where interference-free standard output terminals are required

Typical applications include switching 24 V DC solenoid valves, contactors, relays, lamps and other industrial actuators.

Product Status: Regular Delivery / Current
