1756-L55 1756-M12 Allen Bradley Rockwell ControlLogix Memory Expansion Module Processor

1756-L55 1756-M12 Allen Bradley Rockwell ControlLogix Memory Expansion Module Processor

The 1756-L55 is a ControlLogix controller from Allen-Bradley that requires a GuardLogix Safety Partner Controller, such as the 1756-L7SP or 1756-L8SP, to function in a safety application

The 1756-M12 is a memory module that can be used to increase the memory of the 1756-L55 controller.

HS CODE : 8538909200

  • Product No :

    1756-L55 1756-M12 1756L55 1756M12
  • Manufacture :

    Allen Bradley
  • Size (cm) :

    2 * 1 * 5
  • Weight (kg) :

    0.03
  • Origin :

    USA
  • Warranty :

    12 Month
  • Lead Time :

    Ready Stock
  • Description :

    Memory Module

Product parameters

Model :1756-L55

Series :ControlLogix 5560 Series

Number of channels :16 digital inputs + 16 digital outputs

Input type :24 V DC

Output type :24 V DC

Power supply voltage :24 V DC

Current consumption :14 mA

Power consumption: 3.5W

Isolation voltage :30 V (continuous)

Protection grade :IP1 (Standard)

Operating temperature :0°C to 60°C

Storage temperature :-40°C to 85°C

Relative humidity :5% to 95% (non-condensing)

Installation method: Plug-in rack installation

Compatibility: Supports ControlLogix 5560 series racks (such as 1756-A4 to A17)

Communication protocols: Supports EtherNet/IP, DeviceNet, DH+, ControlNet, etc

Certification: Complies with the basic insulation type, RS-232 port to the system

Functional characteristics

16-channel digital I/O: It offers 16 digital inputs and 16 digital outputs, suitable for a variety of industrial control scenarios.

Support EtherNet/IP: Through Ethernet connection, high-speed and real-time data transmission and control are achieved.

Modular design: Easy to install and expand, supporting flexible system configuration.

Low power consumption design: The current consumption is 14 mA and the power consumption is 3.5 W at 24 V DC.

Isolation protection: Provides a continuous isolation voltage of 30 V to ensure system safety.

Easy to maintain: Modular design, convenient for installation and replacement.

Application scenarios

Industrial automation systems: used for production line control, robot control, process control, etc.

Human-machine interface (HMI) integration: Communicate with HMI devices via EtherNet/IP to achieve data exchange and status monitoring.

Distributed Control System (DCS) : It is used for data acquisition and control in factory automation systems.

Communication with the upper computer (SCADA) : Integrate with the SCADA system via EtherNet/IP to achieve remote monitoring and control.

Equipment monitoring and diagnosis: Through digital I/O interfaces, real-time monitoring of equipment status and fault diagnosis are achieved.

Comparison and summary of 1756-L55 and 1756-M12

Parameter: 1756-L55

Number of channels: 16 inputs + 16 outputs

Applicable scenarios: High-density I/O demands

Scalability: Higher

Cost: Higher

Parameter: 1756-M12

Number of channels: 12 inputs + 12 outputs

Applicable scenario: Medium-density I/O demand

Scalability: Average



Cost: Lower
