1734-IM2 Allen Bradley Rockwell CompactLogix 5370 I/O Module

Product parameters

Module type: POINT I/O Digital AC Input Module

Number of input channels: 2 AC input channels, configured as a single group or two groups

Input voltage:

Nominal input voltage: 220V AC@60 Hz

Input voltage range: 159-264V AC @ 47-63 Hz

Input current:

Conduction state

Minimum 6.2 mA @ 159V AC, 60 Hz

Nominal 8.5mA @ 220V AC, 60 Hz

Maximum 10.2 mA @ 264V AC, 60 Hz

Off status: Maximum 2.9 mA

Turn-off voltage: Up to 43V AC

Input impedance: Nominal 22.3k Ω

Power supply:

Maximum POINTBus current: 75 mA @ 5V DC

External AC power supply: 220V AC @ 60 Hz

Power consumption:

Maximum power dissipation: 0.48W @ 264V AC

Maximum heat dissipation: 1.63 BTU/hr @ 264V AC

Isolation voltage: 240V (continuous), test voltage is 2500V DC, lasting for 60 seconds

Input delay time:

Conduction delay: Maximum 20 ms (fixed hardware filtering)

Turn-off delay: Maximum 20 ms

Installation method: DIN rail installation

Wiring method: Detachable terminal block (RTB), supporting 0.25- 2.5mm ² (22-14 AWG) solid or stranded copper wire, rated temperature 75°C (167°F) or higher, maximum insulation thickness 1.2mm

Terminal screw torque: 0.8 N·m (7 lb·in)

Operating temperature range: -20°C to 55°C (-4°F to 131°F)

Storage temperature range: -40°C to 85°C (-40°F to 185°F)

Protection grade: Open type (no enclosure, IP20)

Compatible terminal bases: 1734-TB, 1734-TBS, 1734-TOP, 1734-TOPS

Key switch position: 8

Supported networks: ControlNet, DeviceNet, EtherNet/IP and other open networks

Certification standards: C-TICK, CE, CUL, GOST, KC, MARINE, UL

Relative humidity: 5-95% (non-condensing)

Vibration: 5 g @ 10-500 Hz (during operation)

Impact: 30 g during operation, 50 g during non-operation

Function

Digital AC input processing

Supports 2 AC input channels, receives 159-264V AC signals, and is suitable for high-voltage switches, relays or other AC devices.

It provides reliable signal detection and is suitable for the common 220V AC systems in industrial environments.

Compact design: As one of the AC input modules with the fewest channels in the POINT I/O series, it occupies a small space and is suitable for high-density installation.

Modular design: Compatible with POINT I/O communication adapters and supports distributed I/O architecture.

Detachable terminal blocks (RTB) simplify wiring and maintenance.

Status monitoring: Equipped with module status, network status, and status indicator lights for each input channel, facilitating real-time monitoring and fault diagnosis.

Low power consumption: The maximum power dissipation is only 0.48W, making it suitable for energy-saving control systems.

High isolation: It provides 240V continuous isolation to ensure the safe separation of on-site signals from the system side.

Application scenarios

Industrial automation: Used in PLC systems, it receives 220V AC signals from AC switches, relays or sensors, and is suitable for factory automation control.

Manufacturing industry: In the automotive manufacturing, packaging machinery, and food and beverage production lines, monitor the status of AC drive equipment, such as motor starters or contactors.

Facility management: In building management systems or factory facilities, it is used to detect the operating status of high-voltage equipment.

Distributed I/O system: In large factories or complex systems, combined with POINT I/O communication adapters, it reduces wiring costs and enhances system scalability.

Space-constrained environments: The compact design makes it suitable for installation on small control cabinets or DIN rails close to on-site equipment.

High-voltage application: Specifically designed for processing 220V AC signals, it is suitable for industrial scenarios that require high-voltage input.
