The OMRON R88M-K05030H is an Accurax G5 series AC servo motor, designed for high-precision positioning and dynamic motion control, and suitable for small-scale automated equipment.
HS CODE : 8538909200
Product No :
OMRON R88M-K05030HManufacture :
OMRONSize (cm) :
4*4*7.6Weight (kg) :
0.4Origin :
JAPANWarranty :
12 MonthLead Time :
Ready DRIVEDescription :
AC SERVO MOTORProduct parameters
Model: R88M-K05030H
Rated power: 50 W
Supply voltage: 200 VAC
Rated speed: 3000 rpm
Maximum rotational speed: 6000 rpm
Rated torque: 0.16 Nm
Instantaneous maximum torque: 0.48 Nm
Rated current: 0.4A
Instantaneous maximum current: 1.5A
Encoder: 20-bit incremental encoder
Rotor inertia: 0.022 × 10⁻⁴ kg·m²
Protection grade: IP67 (Except for shaft openings)
Insulation class: Class B
Operating temperature: 0 to 40 °C
Environmental humidity: 20% to 85% (no condensation)
Shaft type: Straight shaft, no keyway
Brake option: No brake
Certifications: UL, CSA, CE, RoHS
Function
High-precision positioning: 20-bit incremental encoder, supporting sub-micron positioning accuracy.
Compact design: Ultra-small structure, suitable for space-constrained equipment.
High dynamic performance: Maximum rotational speed of 6000 rpm, suitable for fast-response applications.
IP67 protection: Suitable for harsh industrial environments (except for shaft openings).
Low inertia: Suitable for applications with high dynamics and low load inertia.
Flexible control: Supports EtherCAT, MECHATROLINK II, analog/pulse control.
Optional configurations: Available in models with brakes (-BS2) or oil seals (-O).
Application scenarios
Small precision machinery: surface mount technology (SMT) machines, dispensing machines, and micro packaging machines, which require high-precision positioning.
Material handling: Small conveyor belts, sorting devices, providing smooth movement.
Robot technology: Small robot joints or mechanical arms, meeting the requirements of compactness and high dynamics.
Laboratory automation: Precision positioning tables and experimental equipment, meeting high-resolution requirements.
Combined with the reducer: It can be matched with R88G-VRXF15B100CJ (1:15 reduction ratio, matching needs to be confirmed), suitable for low-speed and high-torque scenarios.
