OMRON R88M-1L1K530C LOW-INERTIA AC SERVO DRIVE 1S SERIES

Product parameters

Model: R88M-1L1K530C

Rated power: 1.5kW

Rated voltage: 400 VAC

Rated speed: 3000 rpm

Rated torque: 4.77 Nm

Instantaneous peak torque: 14.3 Nm

Rated current: 4.1A

Instantaneous maximum current: 17.1A

Encoder type: Absolute encoder (23-bit)

Protection grade: IP65 (depending on configuration)

Shaft type: Straight shaft with keys and taps (-S2 model).

Installation method: Flange installation.

Function

High-precision positioning: Equipped with a 23-bit absolute encoder, it provides high-resolution feedback to ensure precise motion control.

EtherCAT communication: Supports high-speed EtherCAT network, suitable for multi-axis synchronization and real-time control.

Low inertia design: Optimized for rapid acceleration and deceleration, suitable for high dynamic response scenarios.

Diversified configuration: Offers options such as with or without brakes, oil seals, keyways, etc., to meet different installation requirements.

Security support: It can be paired with drives that support STO, SS1, and SLS security functions.

Efficient heat dissipation: The design supports long-term high-load operation.

Quick debugging: The 1S series supports multi-axis tuning and simple Settings, reducing installation time.

Application scenarios

Industrial robots: Mechanical arm joint drive, requiring high precision and dynamic response.

CNC machine tools: Provide precise motion control and are suitable for processing such as milling and turning.

Packaging machinery: Used in high-speed packaging lines, such as sealing, labeling, and sorting equipment.

Printing equipment: Ensure high-speed and precise motion control during the printing process.

Semiconductor manufacturing: Applied in high-precision equipment such as wafer handling and surface mount technology (SMT) machines.

Automated production lines: such as conveyor belts and assembly lines, require multi-axis synchronous control.
