Omron C200H Series Modular Programmable Logic Controller PLC System

📦 PRODUCT TITLE

Omron C200H Series Modular Programmable Logic Controller PLC System

📝 PRODUCT INTRODUCTION

The Omron C200H is a highly versatile and field-proven modular programmable logic controller designed for mid-to-large scale industrial automation systems. Renowned for its exceptional reliability and expansive I/O capacity, the C200H system supports a vast selection of interchangeable CPU units, special function modules, and communication interfaces. Its building-block architecture allows factory engineers to customize control panels for precise motion control, analog processing, and distributed networking. Although established as a legacy series, it remains a critical asset in worldwide manufacturing textiles, packaging, and assembly lines due to its rugged performance and massive installed base.

⚙️ TECHNICAL PARAMETERS

Control Method: Stored program method with cyclic scan execution

I/O Capacity: Up to 480 local I/O points, expandable up to 848 points via expansion racks

Program Memory: 2.8K to 7.2K words depending on the selected CPU module

Instruction Execution Speed: Basic instructions at 0.75 microseconds minimum

Power Supply Options: 100V to 240V AC or 24V DC input options

Max Configuration Layout: 1 CPU rack plus up to 2 expansion I/O racks

Supported Module Types: Digital discrete inputs/outputs, high-speed counters, analog I/O, position control, and ASCII communication modules

Communication Interfaces: Host Link via RS-232C or RS-422, Sysmac Bus remote I/O, and peripheral tool ports

Ambient Operating Temperature: 0 to 55 degrees Celsius

💡 KEY FUNCTIONS

Modular Flexibility: Backplane-based design enables hot-swapping and flexible mixing of digital, analog, and specialty modules to meet specific plant needs.

Advanced Task Processing: High-speed counter and positioning modules offload intensive mathematical processing from the main CPU, ensuring stable scan times.

Distributed Remote IO: Utilizes Omron Sysmac Bus network to manage remote sub-assemblies over long distances, reducing heavy field wiring costs.

Reliable Self Diagnostics: Built-in watchdog timer, memory checks, and CPU abnormal monitors continuously evaluate hardware status to prevent erratic machine movements.

Data Retention Backup: Equipped with lithium battery backup to safeguard critical system registers, user programs, and internal counter data during blackouts.

📐 DIMENSIONS

CPU Module C200H-CPU01: Height 130 mm x Width 70 mm x Depth 110 mm

Standard IO Module: Height 130 mm x Width 35 mm x Depth 100 mm

Standard Power Supply: Height 130 mm x Width 80 mm x Depth 110 mm

Backplane Base 5-Slot C200H-BC051: Height 130 mm x Width 295 mm x Depth 35 mm

Backplane Base 8-Slot C200H-BC081: Height 130 mm x Width 400 mm x Depth 35 mm

⚖️ WEIGHT

CPU Module C200H-CPU01: 0.75 kg (1.65 lbs)

Standard IO Module: 0.30 kg (0.66 lbs)

Standard Power Supply: 0.85 kg (1.87 lbs)

Backplane Base 5-Slot: 0.90 kg (1.98 lbs)

Backplane Base 8-Slot: 1.20 kg (2.64 lbs)

All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.
