OMRON NB10W-TWO1B TFT COLOR TOUCH SCREEN HUMAN-MACHINE INTERFACE

Product parameters

Model: NB10W-TW01B

Display screen: Type: 10.1-inch TFT color LCD

Resolution: 800 × 480 pixels (WVGA)

Number of colors: 65,536 colors

Backlight: LED, with a lifespan of approximately 50,000 hours (brightness drops by 40% at 25°C)

Touch screen: Analog resistive film, 1024 × 1024 resolution, with a lifespan of approximately 1 million touch operations

Memory: Internal storage: 128MB (including system area)

External storage: Supports USB storage devices

Communication interface: Ethernet: 1 10/100 Base-T port

USB host: 1 USB 2.0 full-speed Type A (output 5V, 150mA)

USB slave: 1 USB 2.0 full-speed Type B (transmission distance 5 m)

Serial port (COM1) : RS-232C/422A/485 (non-isolated), RS-232C up to 15m, RS-422A/485 up to 500m, D-Sub 9 pins

Serial port (COM2) : RS-232C/422A/485 (non-isolated), the same as above

Power supply: Voltage: 24 VDC ±15% (20.4 to 27.6 VDC)

Power consumption: 8W

Working environment: Temperature: 0°C to 50°C

Humidity: 10% to 90% RH (No condensation)

Protection grade: Front panel IP65

Standard certifications: UL, CSA, CE, GOST-R, EAC, KC, cUL508

Battery life: Approximately 5 years (At 25°C, only the NB10W supports factory battery replacement)

Noise immunity: Compliant with IEC61000-4-4, 2 kV (power line)

Function

High-quality display: 10.1-inch TFT color touch screen, supporting 65,536 colors, with clear display, suitable for complex graphics and data visualization.

Multi-protocol communication: Supports Ethernet, RS-232C, RS-422A/485, and can be connected to OMRON and other brand PLCS.

Flexible interaction: Supports touch screen operation, analog resistive film technology, and has a sensitive response.

It provides a USB host interface and supports USB storage devices for data transmission and project download.

Supports PictBridge printing function, facilitating the printing of screen content.

Software support: NB-Designer software (version 1.20 or higher) is used, supporting Windows system, for interface design, project management and offline/online simulation.

Function

Rich: Supports multi-language interfaces, formula data management, alarm display, trend curves, historical data storage, etc.

Provide security features such as user permission Settings and password protection.

Web interface: Supports remote monitoring and operation through the Web interface (configuration required).

Easy to maintain: Supports USB download/upload of project data, simplifying debugging and maintenance.

Application scenarios

Industrial automation: It is used in factory automated production lines and works in conjunction with PLCS to achieve equipment monitoring, parameter setting and data collection, such as in automotive manufacturing, food packaging and semiconductor production.

Mechanical control: In equipment such as CNC machines and injection molding machines, it provides an intuitive operation interface for real-time monitoring and parameter adjustment.

Process control: Applicable to process control systems in industries such as chemical engineering and pharmaceuticals, it displays trend curves, alarm information and historical data.

Intelligent manufacturing: HMI terminals that support Ethernet communication and are suitable for building intelligent manufacturing systems, enabling device interconnection and remote monitoring.

OEM equipment: We provide cost-effective HMI solutions for OEM equipment manufacturers, which are widely used in packaging machinery, textile equipment, etc.
