IMASO01 ABB ANALOG OUTPUT MODULE

Product parameters

Module type: Analog Output Slave Module

Output channels :8 analog outputs (4-20mA or 1-5VDC)

Output resolution :10 bits

Output accuracy

Voltage mode: ≤0.15% Current mode: ≤0.25%

Output load

Current mode: Maximum 750 ohms; Voltage mode: Minimum 2 kΩ

System compatibility :ABB Infi 90 DCS

Power supply: Compatible with 24Vdc (system standard)

Communication interface :Infi 90 bus interface

Operating temperature :-20°C to +60°C (Typical industrial environment)

Storage temperature :-40°C to +85°C

Humidity :5% to 95% (non-condensing)

Certification options: Standard industrial certifications (CE, UL, etc.)

Function

Analog output processing: It provides 8-channel analog output, supporting 4-20mA or 1-5VDC signals to drive field devices for precise control.

Signal conversion: Convert digital control signals into high-precision analog output to ensure low error and stable transmission.

Modular integration: As a slave module of the Infi 90 system, it supports a master-slave architecture to ensure system redundancy and scalability.

Isolation protection: Built-in channel isolation mechanism to prevent noise interference and fault propagation, and enhance system reliability.

Diagnostic support: It provides status indication and fault detection, facilitating system maintenance and rapid problem identification.

Compatible expansion: Seamlessly integrated with the ABB Infi 90 framework, supporting software configuration and remote monitoring.

Application scenarios

Process control system: DCS applications used in the petrochemical, power and pharmaceutical industries, driving valves, actuators and other equipment to achieve process control.

Industrial automation optimization: In oil refineries, power stations and manufacturing industries, it supports analog output expansion to enhance system response speed and reliability.

Data execution and monitoring: Integrated into the SCADA system for real-time control of signal transmission and process variable regulation.

High-reliability environment: Suitable for heavy industrial and energy equipment, scenarios requiring multi-channel analog output, such as continuous production processes and safety-critical applications, but not for high-speed digital I/O or wireless communication.
