6ES7153-2BA82-0XB0 Siemens SIMATIC ET200M INTERFACE Module

Product parameters

Model: 6ES7153-2BA82-0XB0

Brand: Siemens

Type: Interface Module

Function: Interface module for connecting ET 200M and PROFIBUS DP

Compatibility: Applicable to SIMATIC S7-300 series PLCS

Communication protocol: PROFIBUS DP

Data rate: 12 Mbps

Maximum number of slave stations: 12 S7-300 modules

Redundancy capability: Supports redundant configuration

Timestamp function: Supports timestamp function with an accuracy of 1 millisecond

Supported functions: Supports Drive ES and Switch ES, as well as HART auxiliary variables

64-channel module operation: Supports 64-channel module operation, with 32 signals per slot

Power supply voltage: 24 V DC

Operating temperature: -25°C to +60°C

Dimensions: 40 mm (width) x 125 mm (height) x 117 mm (depth)

Weight: Approximately 360 grams

Function

Connection function: This module is used to connect the ET 200M distributed I/O system and the PROFIBUS DP bus to achieve data exchange and communication.

Data processing: Handle all data exchanges with the PROFIBUS-DP master station to ensure the stable operation of the system.

Diagnostic function: It provides LED status indication, facilitating fault diagnosis and maintenance.

Electrical isolation: Provide electrical isolation between channels to ensure the stability and safety of the system.

Application scenarios

Industrial control: It is used to connect ET 200M and PROFIBUS DP systems and is suitable for control tasks on the production line.

Process control: In industries such as chemical engineering, pharmaceuticals, and food processing, it is used to connect and control distributed I/O systems.

Building automation: Used for equipment control and communication in building management systems.

Traffic control: It is used for the control of traffic lights, subways, elevators and other equipment.

Mechanical manufacturing: It is used for the control of robots, conveyor belts, mechanical arms and other equipment on production lines.

Energy management: It is used for the control and monitoring of equipment in power plants, substations, etc.

Characteristics

High performance: Supports redundant configuration of up to 12 S7-300 modules to ensure the high reliability and stability of the system.

High precision: Supports timestamp function with an accuracy of 1 millisecond, suitable for applications that require precise time synchronization.

Multi-functional: Supports Drive ES and Switch ES, as well as HART auxiliary variables, and is suitable for various industrial automation requirements.

High scalability: Supports 64-channel module operation, with 32 signals per slot, suitable for complex automation systems.
