5069-OBV8S Allen Bradley Rockwell Compact 5000 8 Channel 24VDC Safety Configurable Output Module

Product Parameters

Module Type: Compact 5000 Safety Digital DC Output Module (bipolar, sourcing/sinking)

Safety Ratings:

SIL 3 per IEC 61508

PLe, Category 4 per ISO 13849-1

Output Channels:

8 channels (4 pairs, bipolar, sourcing/sinking for safety applications)

Voltage Range: 18–32 V DC

Nominal Voltage: 24 V DC

Output Current: 1 A per channel (max), 4 A per pair (max)

Off-State Leakage Current: 0.1 mA max

Switching Times:

OFF to ON: ≤500 µs

ON to OFF: ≤500 µs

Module Power (MOD Power): 18–32 V DC (SELV/PELV), 100 mA max current

Sensor/Actuator (SA) Power: 18–32 V DC, 4.2 A max current (includes field-side devices)

Power Dissipation: 3.5 W (8 channels @ 1 A)

Thermal Dissipation: 11.9 BTU/hr

Indicators:

8 channel status LEDs (yellow for active outputs)

1 module status LED (green/red for operational/safety status)

Installation:

DIN Rail: Zinc-plated chromate-passivated steel (EN50022, 35 x 7.5 mm)

Latching Mechanism: Integrated for secure mounting

Environmental Conditions:

Operating Temperature: 0°C to 60°C (32°F to 140°F)

Storage Temperature: -40°C to 85°C (-40°F to 185°F)

Relative Humidity: 5% to 95% (non-condensing)

Vibration: 5 g @ 10–500 Hz

Shock: 30 g (operating), 50 g (non-operating)

Altitude: Up to 2000 m without derating

Enclosure: Open-style (requires protective cabinet, Pollution Degree 2 per EN/IEC0664-1)

Certifications:

UL, cULus, CE, RCM, ATEX, IECEx, KC, China CCC, TÜV (for functional safety)

Compatibility:

Local I/O: Compact GuardLogix 5380 (e.g., 5069-L320ERS2, 5069-L320ERMS3)

Distributed I/O: Via 5069-AEN2TR or 5069-AENTR for Compact GuardLogix 5380 or GuardLogix 5580

Maximum Modules: Controller-dependent (e.g., 16 for 5069-L320ERS2, 24 for 5069-L330ERM), up to 31 per adapter

Safety Communication: CIP Safety over Ethernet/IP

Programming Software: Studio 5000 Logix Designer (version 31 or higher)

UPC/GTIN: 889508141664

UNSPSC: 32151705

Functions

Safety-Rated Output Control:

Drives safety actuators with 8 bipolar outputs, up to 1 A per channel (4 A per pair).

Achieves SIL 3/PLe with bipolar configuration for redundant, fail-safe operation.

CIP Safety Integration:

Supports CIP Safety over Ethernet/IP for secure communication with GuardLogix controllers.

Ensures safety data integrity for critical applications.

Configurable Safety States:

Configurable fault states (Off [default], Hold Last State) for Fault, Program, or Communication Failure modes.

Fast switching times (≤500 µs) for responsive safety control.

Flexible I/O Integration:

Functions as local I/O for Compact GuardLogix 5380 controllers .

Supports distributed I/O via 5069-AEN2TR or 5069-AENTR for Compact GuardLogix 5380 or GuardLogix 5580, up to 31 modules per adapter.

Uses producer/consumer model for efficient safety data exchange.

Network Compatibility:

Integrates with Ethernet/IP networks (1 Gbps, Linear/Star/DLR topologies) via controller or adapter.

Requires separate SA power bus (DC) for field device power, isolated from MOD power (DC).

Diagnostics and Monitoring:

8 yellow channel LEDs indicate active outputs;      1 green/red module LED shows operational/safety status.

Supports diagnostic reporting via Studio 5000.

Environmental Reliability:

DIN-rail mounting with latching mechanism ensures secure installation.

Open-style enclosure requires a protective cabinet for dust/corrosive environments.

Withstands vibration (5 g), shock (30 g operating), and operation at 2000 m altitude.

Application Scenarios

Safety-Critical Automation:

Controls safety actuators in production lines.

Compatible with 5069-L320ERS2 (SIL 2) or 5069-L320ERMS3 (SIL 3) for safety systems.

Machine Safety:

Drives safety relays or valves in machinery requiring SIL 3/PLe.

Fast response (≤500 µs) ensures timely safety actions.

Material Handling:

Manages safety shutdowns in conveyor systems or automated sorting with safety actuators.

DLR topology ensures reliable safety communication.

Process Safety:

Actuates safety devices in chemical, pharmaceutical, or oil/gas processes .

SIL 3/PLe supports high-integrity applications.

Distributed Safety Systems:

Functions as distributed I/O via 5069-AEN2TR/AENTR for factory-wide safety control.

Integrates with GuardLogix controllers for scalable safety networks.

OEM Safety Integration:

Provides safety output control for OEM machinery requiring functional safety.

Compact design (0.87 in. width) fits space-constrained applications.
