5069-ARM Allen Bradley Rockwell Compact I/O Address Reserve Module

Product parameters

Module Type: Compact 5000 I/O Address Reserve Module (ARM)

Module Power supply (MOD Power)

Current: 45 mA @ 18-32 VDC

Power consumption: 1.0W

Heat dissipation: 3.4 BTU/h

Power Passthrough:

MOD Power: 9.55A @ 18-32 VDC

SA Power: 9.95A @ 0-32 VDC 9.975A @ 0-240 VAC, 47-63 Hz (ATEX/IECEx, maximum 125 VAC)

Shell type: Open-Style

Installation method: DIN rail (yellow chromium steel, galvanized)

Working environment

Temperature: 0 to 60°C (32 to 140°F)

Relative humidity: 5-95% (no condensation)

Maximum altitude: 2000 meters

Vibration: 10-500 Hz

Mechanical shock

Operation: 30 g

Non-operating: 50 g

Communication: Supports EtherNet/IP networks as local or distributed I/O for CompactLogix 5380, 5480 or ControlLogix 5580

Certifications: CE, EN, IEC, cULus, ATEX/IECEx

Function

Address reservation: Reserve node or slot addresses for future insertion of specific modules to prevent controller reconfiguration and reduce system downtime.

Simplified expansion: Supports the replacement or addition of modules in the operating system. New modules can be enabled with simple configuration, enhancing system availability.

Power direct connection: Supports MOD and SA power direct connection without consuming SA power, suitable for multi-power system design and enhancing redundancy.

Modular integration: Compatible with the Compact 5000 I/O system, supports up to 31 I/O module expansions, and is suitable for local or distributed EtherNet/IP architectures.

Status indication: Equipped with red/green LED indicator lights to show the operating status of the module, facilitating diagnosis.

Safe installation: It is recommended to use a casing with at least IP54 protection rating, suitable for hazardous locations, and to avoid direct sunlight or ultraviolet radiation.

Application scenarios

System expansion reserve: Reserve slots for automated systems planned for future upgrades, suitable for production line modifications or functional expansions (such as packaging and assembly lines).

High availability control: Replacing or adding modules without downtime, suitable for continuous industrial processes (such as food and beverage, pharmaceuticals).

Distributed control: Through the EtherNet/IP network, it is applied as distributed I/O in CompactLogix 5380 and ControlLogix 5580 systems (such as factory automation).

Modular design: In control systems that require flexible configuration, it simplifies maintenance and upgrades.

Hazardous environment: With appropriate enclosures, it is suitable for industrial sites that need to comply with ATEX/IECEx standards.
