2093-PRS4 Allen-Bradley Rockwell Kinetix 2000 Power Rail

Product parameters

General parameters

Module type: Kinetix 2000 4-axis Slim Power Rail

Product Number: 2093-PRS4 (Series A)

Number of supported modules: Up to 4 modules (1 IAM + 3 AM or shunt module/slot filler)

Installation method: DIN rail or panel installation

Protection grade: IP2X (For indoor use, dustproof and waterproof required)

Operating temperature: 0°C to 50°C

Storage temperature: -40°C to 85°C

Relative humidity: 5% to 95% (non-condensing)

Vibration resistance: 2 g (10-500 Hz, IEC 68-2-6)

Seismic resistance: 15 g (peak at 11 ms, IEC 68-2-27)

Working altitude: Up to 1000 meters (Lower capacity is required for use above this altitude. Maximum storage/transportation altitude: 3000 meters)

Certification: C-TICK, CE, CUL, KC, UL

Electrical parameters

Bus input: 325V DC, maximum 20 A

Control input: 240-425V DC, maximum 2.5A

Connectors: Copper busbars and connectors, with Conformal Coated (Conformal-Coated) connecting pins to enhance durability.

Compatibility

Supported equipment: Kinetix 2000 servo driver series,

Supported controllers: ControlLogix, CompactLogix (via SERCOS interface)

Cable compatibility: Used in conjunction with the 2090-K2CK-COMBO connector kit for I/O and feedback connections of IAM/AM (such as 2090-XXNFMF-Sxx, 2090-CFBM7DF-CEAAxx, etc.)

Function

Power supply and signal distribution

Logic power and control signals are transmitted through copper busbars and connectors from IAM (such as 2093-AC05-MP5) to subsequent axis modules (AM) or other modules.

Supports 4-axis configuration to ensure efficient power and communication distribution for multi-axis servo systems.

Modular design

It provides 4 slots, supporting 1 IAM and up to 3 ams, as well as a shunt module or slot filler, simplifying system expansion and maintenance.

The slim design saves space in the control cabinet and is suitable for compact installation.

High reliability

Conformal coated connecting pins enhance durability and adapt to industrial environments (vibration, electromagnetic interference).

IP2X protection level ensures reliable operation.

Compatibility

Seamlessly integrated with IAM modules such as 2093-AC05-MP5, the connection of motor feedback (15-pin D-Sub) and I/O signal (44-pin D-Sub) is achieved through the 2090-K2CK-COMBO connector kit.

Support SERCOS optical fiber communication, simplify wiring and improve real-time control performance.

Easy to install

Supports DIN rail or panel installation, with locking mechanism, meeting the requirements of shock resistance and vibration resistance.

The modular design facilitates quick installation and replacement.

Application scenarios

Manufacturing industry: Multi-axis servo systems used in automated production lines, such as robot arms and CNC machine tools, ensure precise positioning and speed control.

Packaging machinery: Supports high-speed packaging equipment, and achieves efficient power distribution and signal transmission of servo motors through 2093-AC05-MP5 and 2090-K2CK-COMBO.

Material handling: It is used in systems such as conveyor belts and automatic guided vehicles (AGVs), providing reliable power supply and control signal distribution.

Process control: In scenarios such as printing machines and textile machinery that require multi-axis coordination, ensure the stable operation of the servo drive system.

Robot application: Supports multi-axis robot systems. IAM and AM modules are carried through 2093-PRS4, and high-precision feedback and control are achieved in combination with 2090-K2CK-COMBO.
