1769-OV32T Allen Bradley Rockwell CompactLogix 32 Point Terminated 24VDC Sinking Output Module

Product parameters

Number of output channels: 32 single-ended current output channels

Output range:

0-20 mA

4-20 mA

Resolution:

16-bit digital-to-analog converter (DAC

For 0-20 mA output: 15.91-bit resolution, with A current of 0.323 A per bit

For 4-20 mA output: 15.59-bit resolution, with A current of 0.323 A per bit

Conversion rate:

The conversion rate of all channels is 5 milliseconds

The step response time of 63% of the output is less than 2.9 milliseconds

Power supply requirements:

External DC power supply, voltage range 20.4 to 26.4 volts

The minimum current is 60 milliamperes

Operating temperature range:

0 to 60 degrees Celsius

Output impedance:

Greater than 1 ohm

It has short-circuit protection function

Bus current consumption

At 5 V DC: 145 mA

At 24 V DC: 160 mA

Heat dissipation

Maximum 2.69 watts (the worst case for all channels under a load of 250 Ω)

Accuracy:

At 25°C, the overall accuracy is ±0.35% of the full range

No on-site calibration required (guaranteed by hardware design)

Product function

High-precision output: The 16-bit DAC offers high-precision current output, making it suitable for industrial scenarios that require precise control.

Fast response: With a conversion rate of 5 ms and a 63% step response time of 2.9 ms, it ensures fast response and stable output.

Flexible configuration: Each channel can be independently configured as 0-20 mA or 4-20 mA to meet the requirements of different industrial applications.

Short-circuit protection: The output channel is equipped with a short-circuit protection function to prevent damage caused by overload or short circuit.

Compatibility: Compatible with 1769 and 1768 CompactLogix controllers as well as MicroLogix 1500 controllers.

Modular design: As a single-width module, it can be installed in 1769 and 1768 CompactLogix systems and supports the expansion of I/O racks.

Application scenarios

Industrial automation control: It is widely applied in industrial automation systems that require precise analog signal output, such as in the chemical, petroleum, natural gas, pharmaceutical, and energy industries.

Process control: The final control components (FCE) used to drive the control loop, such as motors, valves, actuators, etc.

Environmental monitoring: It is used for monitoring and controlling temperature, pressure, flow rate, liquid level, etc.

Machine control: In fields such as numerical control machinery, metallurgy, textile printing and dyeing, and automotive manufacturing, it is used for precisely controlling actuators.

Energy management: In fields such as power plants, water conservancy treatment, and environmental protection, it is used to regulate and control the operating status of energy equipment.
