1756-L83ES Allen Bradley Rockwell ControlLogix GuardLogix Controller

Product parameters

Controller type: ControlLogix 5570 series

Processor: 5570 series processor

User memory: 64 MB

I/O memory: 1.96 MB

Non-volatile storage: Supports 1 GB Secure Digital Card (SD1)

Power management: Energy storage modules (capacitors) are used to store the contents of volatile memory

Power supply: It adopts an industrial-grade power interface and supports wide voltage input (such as 100-240 V AC)

Tasks and Programs: Up to 32 controller tasks can be downloaded, and each task contains up to 100 programs

I/O connection: Supports up to 128,000 digital I/O and 4,000 analog I/O

Communication interface: Embedded USB port, with a maximum transmission rate of up to 12 Mbps

Communication protocol: Supports Ethernet /IP, SynchLink, ControlNet, Remote I/O, DeviceNet, Data Highway Plus, etc

Redundant configuration: Supports simple or redundant controller configuration

Controller connection: Up to 500 controller connections can be processed

Safety module: Equipped with three capacitor energy storage modules, two of which are detachable and one is non-detachable

The certification has passed ATEX, CE, UL, China CCC, Australia RCM and other certifications

Functional characteristics

High-performance processing capability :64 MB of user memory and 1.96 MB of I/O memory make it one of the most powerful processors in the Logix 5570 series.

Flexible I/O configuration: Supports up to 128,000 digital I/O and 4,000 analog I/O, suitable for complex industrial automation systems.

Support for multiple communication protocols: Supports multiple communication protocols such as Ethernet /IP, SynchLink, ControlNet, Remote I/O, DeviceNet, Data Highway Plus, etc., facilitating integration with different devices.

Safety features: Equipped with an energy storage module, it ensures the retention of critical data even in the event of a power outage, enhancing system reliability.

Redundant configuration: Supports simple or redundant controller configuration, suitable for industrial environments with high requirements for system reliability.

Easy to program and configure: Provide a graphical programming environment (such as Studio 5000), facilitating users' configuration and debugging.

Environmental protection design: Energy storage modules are adopted to replace traditional batteries, reducing maintenance and replacement costs.

Industrial-grade power supply design: Supports wide voltage input and is suitable for various industrial power supply environments, such as frequency converters, UPS, industrial power distribution systems, etc.

Stronger industrial environment adaptability: Suitable for harsh environments such as high temperature, high humidity, dust, and corrosive gases, with a higher protection level (such as IP21 or higher).

Application scenarios

Manufacturing process control: Applicable to the automation control in factory production lines, such as assembly lines, packaging lines, inspection systems, etc.

Motion control: It can be used to control motion equipment such as motors, servo motors, and robots, achieving precise position, speed, and acceleration control.

Process control: Applicable to industries such as chemical engineering, petroleum, and food processing, it is used to control process parameters such as temperature, pressure, and flow rate.

Data acquisition and monitoring system: Through I/O interfaces and communication modules, sensors and actuators can be integrated to achieve real-time monitoring and data acquisition of the production process.

Machine safety and reliability system: Through safety modules and redundant configurations, it ensures that critical equipment can still operate safely in case of failure or emergency.

Large-scale automation systems: Due to their powerful processing capabilities and flexible I/O configurations, they are suitable for large-scale industrial automation systems, such as smart factories and energy management systems.

Industrial automation with high performance and high reliability requirements: Due to its 64 MB memory and 1.96 MB I/O memory, it is particularly suitable for handling complex control tasks, such as multi-axis motion control, real-time data processing, complex logic control, etc.

Industrial automation in harsh environments: Due to its industrial-grade power interface and higher protection level, it is particularly suitable for use in harsh environments such as high temperature, high humidity, dust, and corrosive gases.
