1756-EN2F Allen Bradley Rockwell EtherNet/IP Communication Module

Product parameters

Type: EtherNet/IP Communication Module (2-Port)

Interface: 2 RJ-45 Ethernet ports, supporting a transmission rate of 10/100 Mbps

Communication protocol: Supports protocols such as CIP, CIP-EDD, CIP-RT, CIP-AC, CIP-AL, CIP-EM, CIP-EC, etc

Redundancy support: Supports redundancy configuration (Redundancy)

Power supply: 24 V DC power supply is provided by the ControlLogix chassis

Environmental protection grade: IP20

Temperature range: -20°C to +60°C

Connection count: Supports 1000 CIP I/O connections and 528 CIP message connections

Security function: Supports CIP Security, providing data encryption and access control

Functional characteristics

High-speed Ethernet communication

Supports 10/100 Mbps Ethernet communication and is suitable for industrial automation systems that require high-speed data transmission.

Supports multiple CIP protocols, including CIP-RT (Real-time), CIP-AC (Motion Control), CIP-AL (alarm), etc., and is suitable for different types of industrial applications.

Redundant configuration

Support Redundancy configuration to ensure that the system can still operate normally in the event of a single point of failure, thereby enhancing the system's availability and stability.

CIP communication protocol:

Supports CIP (Control Interface Protocol) communication protocol and is suitable for integrating complex functions such as motion control, alarm, and data acquisition.

It supports advanced functions such as CIP-EDD (Equipment Description) and CIP-EC (Equipment Configuration), facilitating the integration and configuration of the equipment.

Secure Access: Supports CIP Security, provides data encryption and access control, and ensures the security of the control system.

Flexible network topology: Supports multiple network topology structures, including star, tree and ring, suitable for industrial networks of different scales and complexities.

Industrial-grade design: It adopts industrial-grade design, featuring excellent anti-interference ability, stability and reliability, and is suitable for harsh industrial environments.

Application scenarios

Industrial automation system

1756-EN2F is widely used in industries such as manufacturing, packaging, food and beverage, oil and gas, water treatment, mining and power generation.

It is applicable to industrial control systems that require high-speed Ethernet communication, such as PLC, DCS, SCADA, etc.

Remote monitoring and maintenance: Remote monitoring and maintenance are achieved through EtherNet/IP networks to enhance the maintainability and efficiency of the system.

It supports remote access and data collection, facilitating engineers to conduct remote debugging and troubleshooting.

Data acquisition and transmission

It supports multiple data acquisition and transmission methods, and can transfer controller data in XML or CIP format to various software applications.

It is applicable to industrial scenarios that require a large amount of data processing and analysis, such as quality control, production statistics, etc.

Equipment integration and expansion

The 1756-EN2F can communicate with other EtherNet/IP devices, bridge EtherNet/IP nodes, and transmit messages to devices in other networks.

It is applicable to device integration and expansion in complex network environments.

Building Automation and Process Control

This module is not only applicable to industrial automation systems, but also can be used in building automation and process control fields.
