ZTE ZXRAN V9200 VBPC7 BASEBAND PROCESSING BOARD
ZXRAN V9200 VBPC7 is a baseband processing board in ZTE ZXRAN V9200 5G BBU.
HS CODE : 8538909200
Product No :
ZTE ZXRAN V9200 VBPC7Manufacture :
ZTESize (cm) :
25*12*2.5Weight (kg) :
0.8Origin :
CHINAWarranty :
12 MonthLead Time :
Ready DRIVEDescription :
FUNCTIONAL BOARDProduct parameter
Operating voltage: DC-48V (BBU standard power supply)
Power consumption: approx. 50W to 100W (depending on baseband processing load)
Interface type:
6 10Gbps SFP+ optical ports (for RRU or AAU connection)
Internal high-speed bus interface (communication with other BBU boards)
Processing capacity:
GSM support: up to 48 carriers
UMTS support: up to 24 carriers
LTE FDD support: 6 20MHz 4T4R cells, throughput 12Gbps downstream / 1.8Gbps upstream (subject to license configuration)
Operating temperature: -40°C to +55°C (suitable for equipment room or outdoor cabinet)
Protection Class: IP20 (indoor use)
Feature
Baseband processing: Performs 2G/3G/4G physical layer protocol processing, including modulation demodulation and channel coding
Multi-mode support: Compatible with GSM, UMTS and LTE (FDD/TDD), supporting 2T2R/2T4R/4T4R configuration
Data exchange: Provides grid transmission of IQ data between baseband boards
Interface support: Radio frequency unit (RRU/AAU) connected via CPRI interface
Management function: Integrates with ZTE NetNumen U31 network management system, supports real-time monitoring and software upgrade
Application scenario
Multi-mode base station deployment: For base stations that support 2G/3G/4G coexistence, suitable for the network evolution transition period
Urban coverage: Provide multi-standard network support in densely populated areas to meet diverse user needs
Carrier Network: A wireless access network (RAN) deployed in a telecom operator that supports a macro base or distributed architecture
Capacity expansion: Improves the processing capacity of existing BBus by working with multiple BBus
