YASKAWA SGML-04AF14 AC SERVO MOTOR SIGMA MINI SERIES

Product parameters

Rated power: 400 W (0.4 kW, 0.53 HP)

Rated speed: 3000 RPM

Maximum rotational speed: 5000 RPM

Rated torque: 1.27 N·m

Instantaneous peak torque: approximately 3.81 N·m

Rated current: 2.6A

Input voltage: 200 V AC

Encoder specification: 1024 PPR incremental encoder

Shaft specification: Straight shaft with keyway

Protection grade: IP65

Cooling method: Natural cooling Ambient temperature: 0 to +40°C (operating), -20 to +60°C (storage) Environmental humidity: 20% to 80% RH (no condensation)

Brake: No brake

Oil seal: No oil seal

Certification: Complies with UL, cUL and CE

Function

Compact design: Small in size and light in weight, suitable for space-constrained applications such as chip mounters and semiconductor equipment.

High dynamic response: Low inertia design, supporting rapid acceleration and deceleration, suitable for high-frequency reciprocating motion.

1024 PPR incremental encoder: It offers a resolution of 4096 pulses per revolution (4 times the frequency), meeting the requirements of medium and small precision positioning (lower than the 17-bit encoder of SGMGH-09ACA21).

High reliability: IP65 protection grade, resistant to dust and water splashes, suitable for industrial environments.

Multi-functional control: Supports torque, speed and position control, is compatible with analog voltage/pulse sequence protocols, and is convenient for integration with amplifiers such as SGDL-04AP.

Durability: Cast aluminum housing, built-in overheat protection, compliant with UL, cUL and CE standards, suitable for harsh environments.

Simple installation: Straight shaft design (with keyway or without keyway), facilitating various mechanical connections.

Application scenarios

Semiconductor manufacturing: Used in chip mounting machines and wafer handling equipment, providing high-precision positioning and rapid response.

Electronic production: Drives SMT equipment and PCB assembly lines, supporting high repeatability and miniaturized design.

Packaging equipment: It is used for small packaging machines (such as labeling machines, sealing machines), meeting the requirements of limited space and high precision.

Small robots: Drive lightweight robot joints (such as desktop robots) to provide high dynamic response.

Automated production line: Supports the assembly of small electronic components or the production of precision parts.

Medical equipment: Used for precision medical instruments (such as testing equipment), ensuring stability and precise control.
