Siemens 6SE6400-3TC14-5FD0 MICROMASTER 4 Output Reactor 380–480V 3AC 145A/178A Frame F
The Siemens 6SE6400-3TC14-5FD0 is a standalone output reactor designed for MICROMASTER 4 drive systems operating on 380–480 V three-phase AC. It is used on the motor side of the frequency converter to improve the electrical conditions between the drive and motor.
HS CODE :8504500000
Product No :
6SE6400-3TC14-5FD0Manufacture :
SiemensSize (cm) :
32.1 *35 *28.8Weight (kg) :
56Origin :
Czech RepubliWarranty :
12 MonthLead Time :
Ready StockDescription :
Output ReactorThe 6SE6400-3TC14-5FD0 is a Siemens MICROMASTER 4 output choke/motor reactor in frame size F. It is installed between the frequency converter and motor and provides output-side inductance that helps reduce the effects of high-frequency voltage pulses generated by the inverter. This can help reduce motor-side electrical stress and improve compatibility with longer motor cable installations.
The reactor is rated for 3-phase 380–480 V AC systems and supports 145 A under high-overload/constant-torque (HO/CT) operation and 178 A under low-overload/variable-torque (LO/VT) operation. Siemens documentation identifies the device as an output reactor for MICROMASTER 4 frame-size F drives.
The Siemens technical data sheet specifies approximately 0.469 kW power loss, IP00 protection and M8 power/PE connections. For the exact installation, cable arrangement and thermal clearances, the original Siemens installation documentation should be followed.
Main Features
The Siemens technical documentation specifies maximum motor cable lengths of 200 m shielded or 300 m unshielded for the relevant 380–480 V operating ranges.
Product Lifecycle: PM300 – Active Product
