PHARPSFAN03000 ABB FAN SYSTEM MONITORING AND COOLING MODULE

Product parameters

Dc version: 24VDC, 1.5A; Ac version: 120VAC, 60Hz

Power consumption: Approximately 70W for the AC version

Air volume :280CFM to 500CFM (cubic feet per minute)

Fan speed: Adjustable range 800-1800rpm; Some versions have a maximum RPM of 3000

Noise level :58dB (Standard operating condition)

Operating temperature :0℃-50℃

Sensor configuration: Integrated temperature sensor (real-time temperature measurement), rotational speed sensor (monitoring fan status)

Function

Intelligent heat dissipation control: By using an internal temperature sensor to monitor the device's temperature in real time and automatically adjust the fan speed (adjustable from 800 to 1800rpm), it achieves on-demand heat dissipation and balances heat dissipation efficiency with energy consumption.

System status monitoring: Integrated speed sensor to monitor the fan's operating status in real time (such as stop, abnormal speed), and simultaneously feed back equipment temperature data, supporting fault early warning.

Alarm threshold configuration: Supports customizing temperature alarm thresholds through software. When the limit is exceeded, an alarm will be automatically triggered to remind operation and maintenance personnel to handle it in a timely manner.

High compatibility and adaptation: It can be seamlessly integrated with mainstream industrial control systems such as ABB MPS III automation platform and Beli Infi 90 system, without the need for large-scale modification of existing equipment.

Convenient operation and maintenance design: The compact structure makes it easy to install in various control cabinets, supports quick disassembly and maintenance, and reduces operation and maintenance costs.

Application scenarios

Power industry: Heat dissipation for power plant control systems (such as steam turbine control cabinets, relay protection devices);

Petrochemical industry: Temperature control of control modules for chemical reaction vessels and monitoring equipment for oil and gas transportation pipelines;

Manufacturing industry: Heat dissipation guarantee for PLC control cabinets in automotive production lines and automation equipment in intelligent factories;

Data center: Auxiliary heat dissipation for server cabinets (especially in industrial-grade data centers);

Other fields: shipbuilding control systems, electrical cabinets for mining machinery, heat dissipation for telecommunications base station equipment, etc.
