OMRON R88M-G1K520T-BS2 AC SERVO DRIVE G SERIES

Product parameters

Ambient operating temperature and humidity: 0 to 40°C, maximum 85% RH (no condensation)

Environmental storage temperature and humidity: -20 to 65°C, maximum 85% RH (no condensation)

Working and storage environment: No corrosive gases

Vibration resistance: 10 to 2500 Hz, with maximum acceleration of 49 m/s² in the X, Y, and Z directions

Impact resistance: The maximum acceleration in the X, Y, and Z directions is 98 m/s², three times

Insulation resistance: Minimum 20 MΩ (500 VDC) between the power terminal and the frame ground

Dielectric strength: 1500 VAC between the power terminal and the frame ground for 1 minute (50/60 Hz)

Protection grade: IP65

Insulation class: Type B

Structure: Fully enclosed self-cooling

Installation method: Flange installation

International standard: EU Directive and UK Regulation: Low Voltage (IEC 60034-1/-5)

UL standard: UL1004-1

CSA standard: CSA 22.2 No.100

Electrical and mechanical characteristics: Rated output power: 1.5kW

Rated speed: 2000 r/min

Rated torque: 7.16 Nm

Peak torque: 21.5 Nm

Power supply voltage: 230 VAC single-phase

Encoder type: Absolute encoder (ABS)

Encoder resolution: 17 bits

Shaft diameter: 22mm

Shaft length: 55mm

Shaft features: With keyway and threaded hole (tap)

Whether the motor is equipped with a brake: Yes, it is

Peak performance torque: 300% of the rated torque, sustainable for 3 seconds or longer

Speed control range: 1:5000

Speed change rate: Load characteristic: 0% to 100% (at rated speed) ≤ 0.01%

Voltage characteristic: 0% at ±10% of rated voltage (at rated speed)

Temperature characteristic: ≤ ±0.1% at 0 to 50°C (at rated speed)

Torque control reproducibility: ±3%

Function

High-precision control: The 17-bit absolute encoder offers high-resolution feedback, making it suitable for applications that require precise position control.

Brake design: Built-in ABS brakes enhance safety and emergency stop capability.

High dynamic response: Peak torque reaches 300% of the rated torque, suitable for rapid acceleration/deceleration scenarios.

Multi-control mode compatibility: Supports position control, speed control and torque control.

Protection performance: IP65 protection grade, suitable for various industrial environments.

Simple integration: Supports EtherCAT, MECHATROLINK-II, analog or pulse input, compatible with various servo drives, facilitating system integration.

Application scenarios

Automated production lines: such as packaging machines, labeling machines, and printing machines, require precise motion control.

Robot technology: Industrial mechanical arms or robot joints require high torque and reliable braking.

Electronic manufacturing: SMT equipment, dispensing machines, and testing equipment require high dynamic response and stability.

Material handling: Conveyor belts or logistics equipment require smooth speed control and emergency stop functions.

Processing equipment: such as CNC machine tools and cutting machines, requires high precision and powerful performance.
