NTU-7Q2E ABB INDUSTRIAL-GRADE DIGITAL I/O MODULE

Product parameters

I/O type: Digital input/output (hybrid module)

Number of input channels: 4 digital input channels, supporting dry contact/wet contact signals

Output channel number: 2 digital output channels, using relay output form

Input signal voltage: 24V DC (Industrial standard DC signal)

Output load capacity: Each output channel has a maximum load current of 5A, supporting AC 250V/DC 30V loads

Response time: Input response ≤1ms, output response ≤5ms, ensuring rapid signal processing

Working voltage: 24V DC (Wide voltage fluctuation range ±10%, suitable for industrial power supply environments)

Operating temperature: -30℃ to + 70℃ (resistant to temperature changes in harsh industrial sites)

Insulation class: Insulation voltage between input/output/power supply ≥2.5kV AC (1 minute), ensuring electrical safety

Installation method: DIN rail mounting, compatible with standard 35mm DIN rails, suitable for deployment in industrial control cabinets

Function

Hybrid I/O control: Integrating 4 input channels and 2 output channels, it can simultaneously achieve on-site digital signal acquisition and actuator control, reducing the number of modules and lowering system costs. ​

Strong anti-interference capability: It adopts photoelectric isolation technology (full isolation between input/output and power supply), and is combined with electromagnetic compatibility (EMC) design to effectively resist electromagnetic interference, surge impact and other interference factors in industrial sites, avoiding false signal triggering or module damage. ​

Status monitoring and diagnosis: Built-in channel status indicator lights (input/output corresponding to LED indications respectively), allowing for intuitive determination of signal on/off status. It also supports self-diagnosis of faults. When the output is overloaded, short-circuited or the power supply is abnormal, the fault information is fed back through the indicator light or the system bus, which is convenient for quickly locating the problem. ​

System compatibility: Supports communication with mainstream control platforms such as ABB AC500 series PLC and ABB Freelance DCS system, and is compatible with industrial communication protocols such as Profinet and Modbus-RTU, achieving seamless data interaction with upper-level systems without the need for additional adaptation modules. ​

Durable design: It adopts an industrial-grade flame-retardant housing (compliant with UL94 V-0 grade) and high-reliability components, featuring anti-vibration (5-500Hz, 10g acceleration) and anti-shock (30g acceleration, 11ms duration) capabilities, making it suitable for long-term operation in complex industrial environments. ​

Application scenarios

It is widely applied in digital signal monitoring and execution control scenarios in industrial production processes. It is compatible with fields such as mechanical manufacturing production lines (such as equipment start-stop control, sensor signal collection), safety interlock systems in chemical industrial parks (such as valve switch status monitoring, alarm signal output), water treatment equipment control (such as pump start-stop, liquid level switch signal collection), and power auxiliary equipment control (such as distribution cabinet switch status monitoring, fan start-stop control). It can be integrated into the automation control system as a core I/O unit to enhance the digital control level of on-site equipment.
