NS737D-C CAM-TYPE PNEUMATIC VALVE POSITIONER

Product parameters

Input signal :20-100kPa

Supply pressure :140-700kPa

Output pressure: Compatible with cylinder actuators, up to 1000kPa at most

Action characteristics: Linear characteristics, which can be freely selected and adapted through the CAM

Lag: Less than 1%

Repeatability: Less than 1%

Maximum gas consumption :20nl/min

Connection specifications: The pipe interface is 1/4 inch, and the pressure gauge interface is 1/8 inch

CAM input Angle :60-120°

Function

Precise positioning valve: After receiving pneumatic control signals, it can drive the cylinder actuator to adjust the valve to the corresponding opening degree, effectively overcoming the unbalanced force caused by the friction of the valve packing and the medium pressure. It has a small positioning error and ensures the stable control of fluid flow and pressure.

Flexible adaptation and adjustment: Supports range control (such as 30%-100%, 50%-100%, etc.), can switch between positive and negative action modes, adapt to pipeline systems with different control logics, and the CAM design can also flexibly match the flow characteristics of different valves.

Stable gas path control: It operates stably within a wide supply pressure range of 1.4 to 7kgf/cm², with low gas consumption. Moreover, the output pressure can be adapted to high-pressure cylinder actuators, meeting the driving requirements of valves of different powers.

Reliable signal feedback: When paired with a pressure gauge interface, it can monitor the gas line pressure in real time, facilitating staff to troubleshoot and ensuring the stable operation of the valve control circuit.

Application scenarios

Ship fluid system: Compatible with the cargo oil pipeline and ballast water system of ships, controlling the opening and closing of butterfly valves and other valves to ensure the accuracy of fuel delivery and ballast regulation during ship navigation.

Industrial pipeline control: It is used in steam and liquid medium pipelines in industries such as petrochemicals and power, controlling the opening degree of automatic regulating valves to meet the dynamic regulation requirements of fluid flow and pressure in production.

Gas turbine equipment: Cooling and fuel supply pipelines for gas turbine power units, control valves precisely regulate the medium supply volume to ensure the stable operation of the unit.

General fluid equipment: Auxiliary pipelines suitable for water treatment, chemical reaction vessels and other equipment, achieving automated and precise control of medium transportation.
