HUAWEI CR5DLPUFM37K FLEXIBLE CARD SLOT LINE PROCESSING BOARD

Component code :03050KMD

Model :CR5DLPUFM37K

Single board category: Flexible card-inserting mother board

Silk screen printing

LPUI-483A-CM

24×10GBase-SFP+

Typical power consumption [W]:192.77 W

Typical heat dissipation value [BTU/hour]:624.84 BTU/hour

Long-term operating environment temperature [°C]:0°C to 45°C

Short-term operating environment temperature [°C]:-5°C to +55°C

Basic functions: Supports 480G line-speed forwarding, which can provide users with low-cost and personalized solutions. This board can provide up to one 1/2 wide slot, and one FPIC card can be inserted into each slot. Supports adaptive line-speed forwarding of 24 GE/10GE ports.

Reliability and availability: Supports hot plugging.

Restrictions and Instructions:

Each port group has four ports: 0-3, 4-7, 8-11, 12-15, 16-19, and 20-23, and can operate in 10GE/GE mode. The port group operates by default in 10GE mode and can be adaptively switched to 10GE/GE mode. Within each port group, 10GE LAN or 10GE WAN can be switched on a group basis. The combination of 10GE LAN and 10GE WAN is not supported. 10G WAN only supports Master mode.

When this single board is used in conjunction with 02311GSA and 02314MED optical modules, the optical modules are limited to long-term operating temperatures ranging from 0 to 45 degrees.

When using the electrical port module, there may be interference between the network cable of the electrical port module and the sub-card wrench near the sub-card wrench. It is recommended that the electrical port module only be used for even ports such as 0, 2, 4, 6, 8, 10, 12, 14, 16, 18, 20, and 22.

Whether hashing is supported: No

Whether port rate adaptation is supported: GE/10GE adaptation is supported.

Does it support MACsec? Yes

Does it support the use of RTU? Yes

Ports 0 to 11 are not controlled and are 10GE.

Exit 12-23

The port is not controlled when in GE mode.

When the port is in 10GE mode, it is controlled by default to 100M. If you want to use the bandwidth of other ports, you need to load the RTU.
