HUAWEI CR5DLPUFB070 HIGH-PERFORMANCE LINE CARD

Product parameters

Forwarding capacity: Up to 120 Gbps (full-duplex, line-speed forwarding)

Interface support:

Support multiple seed card modules (such as 10GE SFP+, 100GE QSFP28, GE SFP, etc.)

The specific interface types and quantities depend on the model of the sub-card used in combination

Protocol support:

Ethernet: Supports VLAN, QinQ, and MPLS

Routing protocols: Support OSPF, IS-IS, BGP, MP-BGP, etc

QoS: Supports traffic classification, priority queues, and congestion management

Advanced features: Supports SRv6, EVPN, MPLS VPN, etc

Power consumption: The typical power consumption is approximately 200-300W (depending on the specific sub-card and usage scenario).

Working environment

Operating temperature: 0°C to 45°C

Storage temperature: -40°C to 70°C

Relative humidity: 5% to 95% (non-condensing)

Compatibility: Applicable to models such as NE40E-M2, NE40E-X3/X8/X16, etc

Function

High-performance forwarding

It offers a line-speed forwarding capability of 120 Gbps and is suitable for medium to high throughput scenarios.

Support low latency and high reliability to meet the requirements of the core network.

Flexible interface expansion

Supports multiple sub-card modules (such as 10GE and 100GE interfaces), and enables flexible configuration of port types and densities through sub-cards.

It can be used in combination with other line cards of the NE40E router to expand network capacity.

Advanced QoS Management

Support refined traffic classification, priority scheduling and congestion management.

Provide traffic shaping and congestion avoidance functions to ensure the quality of service for critical businesses.

Multi-protocol support

Supports advanced network technologies such as MPLS, SRv6, and EVPN, and is suitable for complex network architectures.

Compatible with both IPv4 and IPv6 dual-stack, it meets the future network upgrade requirements.

High reliability

Supports hot plugging, which is convenient for maintenance and upgrade.

Combined with the redundant design of the NE40E router, it provides high availability (such as redundancy of the main control board and power supply).

Intelligent operation and maintenance

Supports Telemetry and network automation, facilitating real-time monitoring and fault diagnosis.

Compatible with Huawei iMaster NCE management system to achieve end-to-end network management.

Application scenarios

Operator core network

Deployed in the backbone network or metropolitan area network aggregation layer, it supports traffic processing for medium and high-density ports.

Supports MPLS VPN and SRv6, providing flexible service carrying capacity.

Data Center Interconnection (DCI)

It is used for 10GE/100GE interconnection within or between data centers to ensure low latency and high bandwidth.

Supports EVPN and VXLAN, and is compatible with cloud-based data center networks.

Enterprise Wide area Network

Provide high-performance WAN connections for large enterprises, supporting high-speed communication between branch offices and headquarters.

Provide QoS guarantees to ensure the priority transmission of critical services (such as video conferencing and ERP systems).

5G bearer network

Meet the medium bandwidth requirements of 5G midhaul and backhaul.

Supports network slicing and flexible traffic scheduling, and is compatible with diverse 5G services.

Cloud service provider

Network infrastructure for cloud service providers, supporting medium and high-density connections for virtualized and containerized applications.

It offers high throughput and elastic scalability to adapt to dynamic traffic demands.
