HUAWEI CR5DE1NLAX75 LINE CARD 8000 SERIES

Product parameters

Port configuration: 24 100GBase-QSFP28 ports, supporting QSFP28 optical modules.

Supported flexible rates: 100GE, 50GE, 40GE, 25GE, 10GE (achieved through adapters or branch modules)

Forwarding capacity: Maximum forwarding capacity of a single board: 2.4Tbps or higher

Power consumption:

Typical power consumption: approximately 600-700 watts.

Maximum power consumption: approximately 750-800 watts.

Support protocols and functions:

Supports IPv4/IPv6 dual-stack, MPLS, SRv6, EVPN, VXLAN.

Support QoS (Traffic classification, queue scheduling, congestion management).

Supports network slicing and is suitable for 5G bearer networks.

Support high-precision clock synchronization (IEEE 1588v2, SyncE).

Environmental requirements:

Operating temperature: 0°C to 45°C.

Storage temperature: -40°C to 70°C.

Working humidity: 5% to 95% (non-condensing).

Reliability

Support hot plugging to reduce service interruption during maintenance.

Compatible with the redundant design of the NetEngine 8000 series (control plane, power supply redundancy).

Function

High-density ports: Offer high-density 100G QSFP28 ports or a combination of 100GE/400GE ports, suitable for data center interconnects (DCI) and backbone networks.

Flexible rate adaptation: support for multiple rate (50 ge ge / 100/40 ge / 10 ge ge / 25), 400 new ge support, through the QSFP - DD or QSFP28 module implementation.

Advanced Routing and Forwarding: Supports SRv6, EVPN, MPLS and VXLAN, facilitating the construction of programmable and automated networks.

Network slicing: It provides both hard slicing and soft slicing functions, supporting the low latency and high isolation requirements of 5G bearer networks.

High-precision synchronization: Supports IEEE 1588v2 and Synchronous Ethernet, meeting the clock synchronization requirements of mobile backhaul and financial networks.

Intelligent operation and maintenance

Supports Telemetry and iFIT to achieve real-time traffic monitoring and fault diagnosis.

Green energy conservation

Adopting advanced chip technology, optimizing power consumption and supporting dynamic power management.

Application scenarios

Data Center Interconnection (DCI)

It is used for high-speed interconnection between cloud service providers or enterprise data centers, providing high-bandwidth and low-latency 100G or 400G connections.

Supports VXLAN and EVPN, meeting the requirements of virtualization and multi-tenancy.

5G Bearer network

It provides high bandwidth and network slicing capabilities, supporting 5G fronthaul, midhaul and backhaul networks.

High-precision clock synchronization meets the strict timing requirements of 5G base stations.

Backbone network and metropolitan area network

As a line card for core routers, it is used in the aggregation layer of backbone networks or metropolitan area networks to handle large-scale traffic.

Support SRv6 to achieve network programmability and simplify operation and maintenance.

Enterprise core network

Provide high-performance and reliable core network interconnection for large enterprises to meet the demands of digital transformation.

Support MPLS and QoS to ensure high-priority transmission of critical services.

Finance and High-Frequency Trading Network

Provide low-latency and highly reliable connections to meet the demand of the financial industry for real-time transactions.
