HUAWEI CR5D00EMGF74 FLEXIBLE CARD 40E SERIES

Product parameters

Interface type: 24 1000Base-X SFP ports (Gigabit Ethernet optical interface).

Bandwidth capacity: Each port supports 1 Gbit/s, and the total bandwidth of the full card is 24 Gbit/s (full-duplex).

Optical module support:

Support standard SFP optical modules.

Support different transmission distances.

Protocol support:

Ethernet protocols: IEEE 802.3, VLAN, QinQ, LACP, ERSPAN.

Routing protocols (relying on the main control board and LPU) : OSPF, IS-IS, BGP, MPLS, SR, SRv6.

Multicast protocols: PIM-SM, PIM-DM, IGMP.

QoS functions: traffic shaping, priority queuing, congestion management.

Synchronization function: Supports 1588v2 (depending on configuration and firmware support).

Power consumption: Approximately 50W to 100W.

Operating temperature: 0°C to 45°C.

Storage temperature: -40°C to 70°C.

Humidity: 5% to 95% (non-condensing).

Hot plugging: Supported, allowing for replacement without stopping the machine.

Function

High-density Ethernet connection

It provides 24 gigabit Ethernet optical interfaces (1000Base-X SFP), supporting high-density access and aggregation.

Supports multiple SFP optical modules, adapting to different transmission distances and fiber types (multimode/single-mode).

Flexible interface configuration:

Supports hot-swapable SFP modules, allowing for dynamic adjustment of interface types and distances.

It can be used in combination with other FPics of the LPUF series (such as CR5DLPUF517E) to meet diverse interface requirements.

Multi-protocol support

Support standard Ethernet protocols (IEEE 802.3), including VLAN, QinQ, LACP, and ERSPAN.

Supports advanced routing functions (relying on the main control board and LPU), such as MPLS, VPN, SR, and SRv6.

Supports the 1588v2 timing protocol (depending on firmware and optical module support), suitable for high-precision synchronization scenarios.

High reliability

Supports hot plugging, allowing for the replacement or upgrade of flexible cards without stopping the machine.

The redundant design in coordination with LPUF ensures the high availability of the network.

QoS and Traffic Management

Support traffic shaping, priority queuing and congestion management to optimize network performance.

It provides ACL (Access Control List) functionality, supporting traffic filtering and security policies.

Intelligent management

Integrate Huawei iMaster NCE management platform, supporting automated configuration, monitoring and fault diagnosis.

It provides Telemetry functionality to analyze port status and traffic in real time.

Security features:

Supports MACsec encryption (depending on SFP module and firmware support).

Built-in DDoS defense function enhances network security.

Application scenarios

Operator backbone network: It provides high-density gigabit Ethernet interfaces for traffic aggregation and backbone network interconnection.

Applicable scenarios: Metropolitan Area Network (MAN), Wide Area Network (WAN), MPLS VPN network.

Data center network: Supports gigabit Ethernet connections in the core or aggregation layer of the data center, meeting the high-density access requirements of servers and storage devices.

Applicable scenarios: cloud computing data centers, enterprise private clouds, and hybrid cloud interconnection.

Enterprise core network: It provides large enterprises with highly reliable and high-density Ethernet interfaces, supporting the interconnection between branch offices and data centers.

Applicable scenarios: Headquarters networks in industries such as finance, manufacturing, education, and energy.

5G bearer network: It provides a gigabit Ethernet interface, supporting low-latency connections between 5G base station backhaul and edge computing nodes.

Applicable scenarios: 5G fronthaul/midhaul/backhaul networks, edge computing deployment.

Intelligent campus network: In conjunction with Huawei's CloudCampus solution, it provides high-density access ports to meet the connection requirements of devices within the campus.

Applicable scenarios: Smart parks, campus networks, hospital networks.
