Huawei CloudEngine S5735I-S8U4XN-V2 Industrial Ethernet Switch, 8-Port GE PoE++ + 4-Port 10GE SFP+, DIN-Rail, Dual Redundant DC Power

The S5735I-S8U4XN-V2 is designed for high-bandwidth industrial access and aggregation applications. It provides 72 Mpps forwarding performance and 96 Gbps switching capability, while supporting up to 520 Gbps system switching capacity. The eight copper ports support Gigabit Ethernet and PoE++, while four 10GE SFP+ ports provide high-speed fiber uplinks.

The switch supports PoE++ with up to 400 W total PoE power under an external 56 V DC power configuration, and can provide up to 90 W per port depending on the PoE standard and power configuration. It supports 1+1 power supply backup and can operate with the PAC240S56-CN 240 W AC power adapter or an external 56 V DC power supply.

Its fanless design, IP40 protection, DIN-rail installation and extended-temperature capability make it suitable for industrial control cabinets and outdoor/harsh-environment networking applications.

Main Features

• 8 × 10/100/1000BASE-T Ethernet ports with PoE++
• 4 × 10GE SFP+ optical uplink ports
• 72 Mpps forwarding performance
• 96 Gbps switching capability
• Up to 520 Gbps system switching capacity
• Up to 400 W PoE power with external 56 V DC supply
• 1+1 redundant power supply design
• DIN-rail mounting
• Fanless / natural heat dissipation
• IP40 industrial protection
• Industrial extended-temperature design
• Layer 2 and Layer 3 switching functions
• Supports VLAN, QoS, ACL, SNMP, RMON, Netconf/YANG, telemetry and other network-management functions.

Application Scope

• Industrial Ethernet networks
• Factory automation and smart manufacturing
• Industrial control cabinets
• Smart mining and mining communication networks
• Smart transportation
• Electric power and utility networks
• Safe-city infrastructure
• Outdoor industrial networking
• Industrial surveillance and IP camera networks
• High-bandwidth PoE device access
• Enterprise/campus network access and aggregation
