ebm-papst W4D500-GM03-01 HyBlade AC Axial Fan, 500 mm, 400 V, 3-Phase, 720 W, 1390 RPM, IP54

The ebm-papst W4D500-GM03-01 is a large-diameter HyBlade axial fan designed for efficient air movement in industrial and commercial ventilation systems. The fan has a 500 mm nominal size and is driven by an M4D110-GF three-phase AC motor.

At 400 V / 50 Hz, the motor can be operated in either delta or star configuration. In the nominal delta configuration, the fan operates at approximately 1,390 RPM, consumes approximately 720 W, and draws approximately 1.41 A. At 400 V / 50 Hz star connection, the speed is approximately 1,180 RPM and power consumption approximately 550 W. The motor also supports 400/460/480 V operating configurations depending on frequency and wiring.

The fan has a five-blade rotor, galvanized and coated sheet-steel housing, black-coated steel guard grille, ball bearings, thermal overload protection and IP54 protection. Airflow direction is V, and the standard direction of rotation is counterclockwise when viewed toward the rotor.

Main Features

• ebm-papst HyBlade axial fan
• Model: W4D500-GM03-01
• 500 mm fan size
• M4D110-GF three-phase AC motor
• 400 V nominal supply
• 3-phase AC operation
• 50/60 Hz
• 720 W power consumption at 400 V / 50 Hz Δ
• 1.41 A at 400 V / 50 Hz Δ
• Approximately 1,390 RPM at 400 V / 50 Hz Δ
• 5 blades
• IP54 protection
• Insulation class F
• Ball bearings
• Thermal overload protection
• Terminal-box connection
• Airflow direction V
• S1 continuous operating mode
• CE compliant

Typical Applications

• Industrial ventilation
• HVAC equipment
• Air-handling units
• Refrigeration systems
• Condensers and heat exchangers
• Cooling equipment
• Industrial cooling
• Cabinet and equipment ventilation
• Commercial air-conditioning systems

Discontinued / EOL – Available from remaining stock and aftermarket suppliers

Replacement / Successor: W4D500-GM03-10 (application compatibility to be verified)
