Eaton MTL MTL7796+/- Intrinsically Safe Zener Barrier for Vibration Probes

The MTL7796 is a passive intrinsically safe interface barrier designed to limit voltage and current transferred from the safe area into a hazardous area. It uses Zener-diode and resistor protection to provide electrical isolation/protection for hazardous-area instrumentation.

The MTL7796+ is intended for positive-polarity systems, while MTL7796- is intended for negative-polarity systems. The product is particularly associated with 3-wire vibration probes used in machinery vibration monitoring systems.

Key Features

• Eaton MTL7700 Series
• Model: MTL7796+ / MTL7796-
• Intrinsically safe Zener barrier
• Shunt-diode safety barrier
• Designed for vibration probes
• Available in positive and negative polarity versions
• 3-wire vibration monitoring transmitter applications
• Hazardous-area protection
• Removable terminals
• Terminals accommodate conductors up to 2.5 mm²
• Typical weight approximately 140 g
• ATEX / IECEx / CSA / UL and other certification coverage depending on variant and market

Main Applications

Vibration Monitoring

Machinery Condition Monitoring

Turbine Monitoring

Compressor Monitoring

Rotating Machinery Monitoring

Hazardous Area Instrumentation

Intrinsically Safe Instrumentation

Oil & Gas

Petrochemical

Power Generation

Process Automation

Product Status: Active / Current

Availability: Current / Supplier Stock
