BENTLY NEVADA 3500/20 125760-01 DATA MANAGER I/O MODULE

Product parameters

Manufacturer :Bently Nevada (Baker Hughes)

Model :3500/20-01-02-00

Order Number :125760-01

Interface type :RS232/RS422, supports external modems

Cable length

RS-232: Maximum 30 meters (100 feet); RS-422: Maximum 1,200 meters (4,000 feet)

Baud rate: Maximum 38.4 kbaud (some sources mention that it can reach up to 115,200 bps)

Protocol support :Bently Nevada proprietary protocol, Modbus RTU and ASCII

Channel support

Analog input/output: up to 16 channels; Digital input/output: up to 8 channels

Installation location: Rack slot 1 (adjacent to the power supply)

Compatibility: Supports external communication processors such as TDXnet, TDIX, and DDIX; Suitable for 3500 series racks

Function

Rack configuration and data acquisition: Configure 3500 racks through a proprietary protocol to retrieve mechanical operation parameters such as vibration, temperature, and rotational speed.

Communication support: It provides RS232/RS422 interfaces and supports the Modbus protocol, seamlessly integrating with external devices such as DCS or SCADA systems.

External processor compatibility: It can be used in conjunction with communication processors such as TDXnet, TDIX, and DDIX to expand data transmission capabilities.

Non-critical path function: Supports data management I/O, but does not participate in the core monitoring path to ensure system reliability.

Remote communication: Supports long-distance data transmission through the RS422 interface, suitable for distributed industrial environments.

Application scenarios

Mechanical condition monitoring: It is used for vibration and condition monitoring of rotating equipment (such as turbines, compressors, and pumps) in the oil, gas, power plants, and manufacturing industries.

Industrial automation: As the communication interface of 3500 racks, integrated with Bently Nevada System 1 software or other control systems for real-time data analysis.

Predictive maintenance: By continuously monitoring the health status of equipment, it reduces unexpected downtime and enhances the efficiency of asset management.

Remote monitoring: Suitable for scenarios requiring long-distance communication, such as offshore oil and gas platforms or large industrial parks, ensuring remote data access and system configuration.
