ABB SACE Formula A3N 400 1SDA066561R1 MCCB, 3-Pole, 400A, Thermomagnetic Trip

Home

ABB

ABB SACE Formula A3N 400 1SDA066561R1 MCCB, 3-Pole, 400A, Thermomagnetic Trip

1SDA066561R1 ABB
1SDA066561R1 ABB

ABB SACE Formula A3N 400 1SDA066561R1 MCCB, 3-Pole, 400A, Thermomagnetic Trip

The ABB 1SDA066561R1 is a SACE FORMULA A3N 400 molded-case circuit breaker (MCCB) with three poles and a rated current of 400 A. It features a fixed thermomagnetic TMF trip unit, front terminals, and an A3N frame.

HS CODE : 8535292000

  • Product No :

    1SDA066561R1

  • Manufacture :

    ABB

  • Size (cm) :

    20.5 *13.95 *10.35

  • Weight (kg) :

    4.561

  • Origin :

    Italy

  • Warranty :

    12 Month

  • Lead Time :

    Ready Stock

  • Description :

    Molded Case Circuit Breaker (MCCB)
Inquiry now

The ABB SACE FORMULA A3N 400 1SDA066561R1 is a fixed three-pole molded-case circuit breaker rated at 400 A. It incorporates a fixed thermomagnetic release with a thermal overload setting of 400 A and magnetic instantaneous protection up to 4000 A.

The MCCB has a rated insulation voltage of 690 V, rated operational voltage of 550 VAC / 250 VDC, and a rated impulse withstand voltage of 6 kV. Its service short-circuit breaking capacity varies according to the operating voltage, reaching 18 kA at 380–440 VAC and 12.5 kA at 480 VAC.

 Main Features & Applications

  • ABB SACE FORMULA A3N series
  • Molded Case Circuit Breaker (MCCB)
  • 3-pole configuration
  • 400 A rated current
  • Fixed installation
  • Thermomagnetic TMF trip unit
  • Thermal protection: 400 A
  • Magnetic protection: up to 4000 A
  • Front terminals
  • Rated insulation voltage: 690 V
  • Rated operational voltage: 550 VAC / 250 VDC
  • IEC compliant
  • Mechanical durability: 5,000 cycles
  • Electrical durability: 2,000 cycles

Application Scope:

  • Low-voltage power distribution
  • Industrial electrical distribution systems
  • Commercial building electrical systems
  • Main distribution boards
  • Switchboards and switchgear
  • Motor and equipment feeder protection
  • Transformer feeder protection
  • Industrial machinery protection
  • Overload protection
  • Short-circuit protection
  • Electrical panel assemblies
  • Factory power distribution systems

Current / Active — Not confirmed discontinued.
