ABB OS400D12LR-114 Switch-Fuse Disconnector, 400A, 3-Pole, 1000V AC, DIN Fuse Type

Home

ABB

ABB OS400D12LR-114 Switch-Fuse Disconnector, 400A, 3-Pole, 1000V AC, DIN Fuse Type

OS400D12LR-114 ABB

ABB OS400D12LR-114 Switch-Fuse Disconnector, 400A, 3-Pole, 1000V AC, DIN Fuse Type

The ABB OS400D12LR-114 (1SCA102413R1001) is a 3-pole switch-fuse disconnector rated for applications up to 400 A. It belongs to ABB's OS series and is designed for switching and isolation applications in low-voltage power distribution systems.

HS CODE :8535301090

  • Product No :

    OS400D12LR-114

  • Manufacture :

    ABB

  • Size (cm) :

    To be verified

  • Weight (kg) :

    9.6

  • Origin :

    Switzerland

  • Warranty :

    12 Month

  • Lead Time :

    Ready Stock

  • Description :

    Switch-Fuse Disconnector
Inquiry now

The OS400D12LR-114 is a manually operated ABB switch-fuse disconnector designed for demanding industrial power distribution applications. Its integrated fuse-switch construction allows the circuit to be switched and isolated while providing fuse-based overcurrent protection when the appropriate fuse links are installed.

The unit is configured for left and right cable entry, supports busbar mounting and is suitable for use as a main switch or safety switch. Available specifications identify a maximum operational voltage of 1000 V AC and an AC-23 operational power rating of 335 kW at 400 V.

The 3-pole configuration and 400 A rating make it suitable for high-current three-phase systems. The LR-114 configuration provides the specified left/right connection arrangement, while the modular OS-series design supports flexible installation.

Key Features

  • ABB OS series switch-fuse disconnector
  • Model: OS400D12LR-114
  • ABB part number: 1SCA102413R1001
  • 3-pole
  • 400 A
  • Maximum operational voltage: 1000 V AC
  • AC-23A operational power: 335 kW @ 400 V
  • Left/right cable connection arrangement
  • Suitable for busbar mounting
  • Manual operation
  • Main-switch function
  • Safety-switch function
  • Integrated fuse chamber
  • IEC and UL approvals for the OS product family

Main Applications

  • Industrial power distribution
  • Main electrical isolation
  • Motor control
  • Transformer protection
  • Switchboards
  • Distribution panels
  • Industrial machinery
  • High-current three-phase systems

Product Status: Current / Available
