6ES7414-2XK05-0AB0 Siemens SIMATIC S7-400 CPU 412-2 CENTRAL PROCESSING UNIT

Product parameters

Model: 6ES7414-2XK05-0AB0

Product Type: SIMATIC S7-400 Series Central Processing Unit (CPU 414-2)

Working memory: 1 MB (0.5 MB code, 0.5 MB data)

Interface:

First interface: MPI/DP, 12 Mbit/s (RS485/Profibus)

Second interface: PROFIBUS DP

Firmware version: V5.3

Programming software: STEP7 V5.3 SP2 or higher version, including hardware updates

CiR synchronization time: 100 ms for base load, 120 µs per I/O byte

Power supply:

Power supply: Through the system power supply (no independent power demand)

Backplane bus current: 5V DC, typically 1.5A, maximum 1.6A

24V DC backplane bus: Up to 300 mA

Current consumption of MPI/DP interface: no more than 150 mA per interface

Processing time:

Bit operation: approximately 45 ns

Word operation: approximately 45 ns

Fixed-point operation: approximately 45 ns

Floating-point operation: approximately 135 ns

Memory

Data blocks (DB) : Up to 6,000, with a maximum of 64 KB per block

Function blocks (FB/FC) : Up to 3000, with a maximum of 64 KB per block

Process image: 8 KB each for input and output (adjustable)

Operating temperature: 0°C to 60°C

Certification: CE, in compliance with industrial standards

Status: Discontinued. The replacement model is 6ES7414-2XL07-0AB0 or a higher-performance CPU (such as 6ES7414-3XM07-0AB0).

Function

High-performance processing: 1 MB working memory, supporting complex control tasks of medium-sized automation systems, fast processing speed, suitable for high-precision operations.

Dual interface communication

The MPI/DP interface supports multi-point communication and distributed I/O control, with a transmission rate as high as 12 Mbit/s.

The PROFIBUS DP interface is used to connect distributed devices, such as sensors, actuators or HMIS.

Multi-cpu support: Supports up to 4 cpus for Multicomputing, suitable for high-availability systems.

Diagnostic function: It provides advanced diagnostic functions and monitors the system status through LED indications (INTF, EXTF, BUS1F, BUS2F, FRCE, RUN, STOP).

Flexible expansion: Supports 1 central rack and 21 expansion units, with a maximum support of 65,536 digital channels and 4,096 analog channels.

CiR support: Supports Configuration in RUN, allowing system configuration to be modified during runtime and reducing downtime.

Programming flexibility: Compatible with the STEP7 programming environment, supports multiple programming languages (such as LAD, FBD, STL), and the maximum number of data blocks and function blocks is 6000 and 3000 respectively.

Application scenarios

Industrial automation: It is used in medium-sized factory automation systems, such as production line control in the automotive manufacturing, food and beverage, or packaging industries, to manage complex control logics and a large number of I/O devices.

Process control: Applied in the chemical, petrochemical or pharmaceutical industries, it handles high-precision and complex process control tasks to ensure process stability and safety.

Infrastructure: It is used in building management systems (BMS), water treatment plants or power distribution systems, supporting the high-reliability operation of critical equipment.

Distributed control: Through the PROFIBUS DP interface, it is suitable for distributed I/O systems, such as remote monitoring and control applications.

High availability scenarios: In scenarios that require redundant configurations (such as energy, steel, or mining), high reliability and fault tolerance are provided through multi-CPU support.
