6ES7350-2AH00-0AE0 Siemens SIMATIC S7-300 High-SpeedCounter Module

Product parameters

Model: 6ES7350-2AH00-0AE0

Product type: SIMATIC S7-300, FM 350-2 counting module

Power supply:

Supply voltage: 24 V DC (Load voltage L+)

5 V DC from the backplane bus: Maximum 110 mA

Power consumption: Typical value 3.5W

Counting channel:

Number of channels: 8 independent counting channels

Counting frequency: Up to 20 kHz (per channel)

Encoder support: 24V incremental encoder

Function support:

Counting function

Frequency measurement

Speed measurement

Measurement of cycle duration

Proportional distribution (ingredients)

Connector: 1 x 40-pin front connector

Configuration: Includes configuration software packages and electronic documents (CD-ROM)

Ambient temperature

Operation: 0°C to +60°C

Storage: -40°C to +70°C

Protection grade: IP20

Certification: Complies with standards such as CE, UL, and CSA

Note: The module was discontinued on 1 October 2014 and succeeded as 6ES7350-2AH01-0AE0

Function

Multi-channel counting: It offers 8 independent counting channels and supports a counting frequency up to 20 kHz, making it suitable for high-precision counting tasks.

Multi-functional measurement

Frequency measurement: Measure the frequency of the input signal.

Speed measurement: Calculate the rotational speed through the encoder signal.

Periodic duration measurement: Measure the periodic time of the signal.

Proportional distribution: Supports ingredient control and is suitable for precise measurement applications.

Encoder support: Compatible with 24V incremental encoders, suitable for a variety of industrial sensors.

Modular design: Seamless integration with SIMATIC S7-300 and ET200M systems, DIN rail mounting, space-saving.

Simple configuration: Comes with a configuration software package (CD-ROM), supporting STEP 7 programming to simplify parameter setting and debugging.

High reliability: Designed for industrial environments, it features anti-interference capabilities and stable operation characteristics.

Application scenarios

Industrial automation: It is used in production line control, packaging machinery, and conveying systems to perform high-precision counting and speed monitoring tasks.

Process control: Applied in industries such as petrochemicals, pharmaceuticals, and food and beverages, it controls the batching process or monitors the operating status of equipment.

Mechanical manufacturing: Integrated into OEM equipment, such as CNC machines, automated assembly lines or robots, for precise counting and speed measurement.

Distributed control: Used in conjunction with ET200M and PROFIBUS DP, it is suitable for distributed control systems in factory workshops or large facilities.

Motion control: It is used to monitor the speed or cycle of rotating equipment (such as motors, pumps) and optimize the motion control system.

Material handling: Used in material handling systems to precisely measure materials or control conveying speeds.
