6ES7315-2EH14-0AB0 Siemens Simatic S7-300 CPU 315-2 PN/DP Central Processing Unit

Product parameters

Working memory: 384KB.

Processor speed: approximately 1.2ns per operation.

Communication interface: Integrated PROFINET interface with a 2-port switch; Supports PROFIBUS DP with high transmission rate; It also features an MPI interface for connecting HMI and programming devices.

Power supply: 24VDC.

I/O capacity: Up to 32 modules can be controlled.

Cycle time: Approximately 60µs per 1K instruction in bit operations.

Operating temperature: 0°C to + 60°C

Storage temperature: -40°C to + 70°C.

Function

Integrated system diagnosis: System diagnosis information is consistently displayed in plain text form on the display screen, TIA Portal, human-machine interface device and Web server. It will be updated even when the CPU is in stop mode and is integrated into the CPU firmware without special configuration.

Security features: Knowledge protection through passwords to prevent unauthorized reading and modification of program blocks; Through copy protection, the program blocks and serial numbers of the SIMATIC memory card can be bound. Communication between HMI devices can be restricted. The controller can identify changes and unauthorized transmission of engineering configuration data.

Data storage and processing: SIMATIC memory cards can be used as insertable loading memory, or for firmware updates. They can also be used to store additional documents or csv files. Data storage/reading can be achieved by creating data blocks through system functions in user programs.

Programming and Operation: Program using STEP 7 Professional V13 or later version; The monitor can display overview information, diagnostic information, etc., and also perform operations such as setting CPU addresses, dates and times, and selecting operation modes.

Application scenarios

Manufacturing industry: It can be used for the automatic control of production lines, real-time monitoring of each link, and ensuring the efficiency and stability of the production process, such as the automotive industry, general mechanical engineering, special mechanical manufacturing, etc.

In the energy sector: Real-time monitoring and control in power generation, distribution and power dispatching, with the ability to monitor and control energy consumption, helps enterprises achieve energy conservation and consumption reduction.

In the water treatment industry: In sewage treatment systems, automatic control of pumps, valves and other equipment is achieved to enhance treatment efficiency.

In the field of transportation: It can be used for the automation of metro systems, signal control and traffic flow management, ensuring smooth and safe traffic.
