6ES7314-1AG14-0AB0 Siemens Simatic S7-300 CPU 314 Central Processing Unit
6ES7314-1AG14-0AB0 is a CPU module from the SIMATIC S7-300 series manufactured by Siemens.
HS CODE : 8538909200
Product No :
6ES7314-1AG14-0AB0 6ES73141AG140AB0Manufacture :
SiemensSize (cm) :
12.5 * 13 * 4Weight (kg) :
0.315Origin :
GermanyWarranty :
12 MonthLead Time :
Ready StockDescription :
CPUTechnical parameters
Power supply voltage: DC 24V, allowable range: DC 19.2-28.8V, minimum value of external fuse device for power supply wire is 2A, power-off/power-off jumper time is 5ms, minimum repetition rate is 1s.
Input current: The rated value of the consumption current is 650mA, the typical no-load value is 140mA, and the typical on-state current value is 3.5A.
Memory: The working memory integrates 128KB and is non-expandable. The residual magnetic memory for the remaining data module is 64KB in size. It supports pluggable MMC with a maximum value of 8Mbyte. The minimum data management period on the MMC (after the previous programming) is 10 years.
Processing time: The typical value for bit operations is 0.06μs, for word operations is 0.12μs, for fixed-point operations is 0.16μs, and for floating-point operations is 0.59μs.
Component quantity: A total of 1024 (DB, FC, FB), among which the maximum number of DB is 1024, the number bars range from 1 to 16,000, and the maximum capacity is 64kbyte. The maximum quantity of both FB and FC is 1024, the number bars range from 0 to 7999, and the maximum capacity is 64kbyte.
Function
The module is equipped with an MPI interface and can be used for communication with programming devices, other PLCS, etc. It supports multiple organizational blocks (OBS), such as cyclic OB (OB1), time alarm OB (OB10), delayed alarm OB (OB20, OB21), etc., which can meet different control requirements and event handling requirements.
Application scenarios
6ES7314-1AG14-0AB0 can be applied in fields such as manufacturing, chemical engineering, energy, and transportation. For instance, it enables real-time data exchange among robots, sensors, and PLCS on automotive assembly lines, and ensures rapid data transmission in automatic control systems of coal mines.
Advantage Products:
| DANFOSS | VLT® AutomationDrive,Plus+1®,MCP | ||
| KEYENCE | KV-800,KV-300,KP-3000,KP-7000,KJ,KV-Nano,HMI | ||
| GE FANUC | PACSystems RX3i,90-30,90-70 | ||
| SCHNEIDER | Modicon M340,Modicon M580,Modicon X80,Pioneer | ||
| BENTLY NEVADA | 3500/94,3500/53,3500/22M,3500/42M,330180-90-00 | ||
| HONEYWELL | Experion® PKS,ControlEdge™ ,HC900 | ||
| ALLEN BRADLEY | CompactLogix,ControlLogix, MicroLogix,Flex I/O | ||
| WESTINGHOUSE | Westinghouse Modbus,Westinghouse 9080,Westinghouse 8000,Westinghouse 1000 | ||
All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.
Many Available just wait for you, feel free to ask to get better deal!!!
|
Conditions |
Original Brand New |
|
Approximate Lead Time |
3-5 days |
|
Warranty |
One Year |
|
Online Service |
24 / 7 |
|
Express Company |
DHL / FedEx / UPS / TNT etc. |
|
MOQ |
1 Piece |
TZ Tech is not an authorized surplus dealer or affiliate for the Manufacturer of this product.
The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because TZ Tech is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply.
While many PLC products will have firmware already installed, TZ Tech makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application.
TZ Tech also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source.
TZ Tech also makes no representations as to your right to install any such firmware on the product.
TZ Tech will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.
