3RW3037-1BB04 SIEMENS SOFT STARTER SIRIUS 3RW30 SERIES

Product parameters

Series: SIRIUS 3RW30

Model: 3RW3037-1BB04

Type: Soft Starter (Two-phase Control)

Application: Three-phase asynchronous motor

Electrical parameters:

Rated power: 18.5kW (400V, 40°C)

Rated working current: 38 A (40°C)

Rated working voltage: 200-480V AC (50/60 Hz)

Control voltage: 24V AC/DC

Current range: 38 A (Standard application)

Maximum starting current: It can be adjusted through the current-limiting function to reduce the starting impact

Overload protection: Built-in electronic overload protection

Power loss: approximately 1.5W (during operation), and even lower in standby mode

Protection level: IP20 (Suitable for installation in control cabinets)

Connection and wiring:

Wiring method: Screw terminal

Main circuit connection: Supports 14-6 AWG wires

Control circuit connection: Supports 20-12 AWG wires

Environmental Specification:

Operating temperature: -25°C to +60°C (derating may be required when the temperature exceeds 40°C)

Storage temperature: -40°C to +80°C

Relative humidity: 10% to 95% (no condensation)

Maximum working altitude: 1000 meters (derating is required for altitudes above this.)

Certification and Standards

Certification: CE, UL, CSA, CCC, ATEX (Applicable to increased safety explosion-proof motors, in compliance with the 94/9/EC Directive)

Standard: IEC 60947-4-2 (Low-voltage Switchgear)

Installation method: DIN rail installation or screw fixation, suitable for installation inside control cabinets

Space requirements: Compact modules, suitable for control cabinets with limited space

Function

Soft start and soft stop

Smooth start-up is achieved through an adjustable voltage ramp, reducing the current impact during start-up (up to three times the rated current), and protecting the motor and the power grid.

It provides a soft stop function to gradually reduce the voltage and avoid the "water hammer effect" in the water pump system.

Two-phase control technology

Two-phase control is adopted to minimize the three-phase current during the start-up process, eliminate the DC component and reduce electromagnetic interference.

Avoid the current and torque peaks generated by traditional star-delta starters.

Built-in protection function:

Overload protection: Built-in electronic overload protection to prevent the motor from overheating.

Phase failure protection: Detect power phase failure to prevent motor damage.

Over-temperature protection: Monitor the temperature of the soft starter to prevent overheating faults.

Self-diagnostic function: Detect internal faults and provide status feedback.

Parameter adjustment

Supports parameter adjustment such as startup time and current-limiting value to adapt to different load characteristics.

The front knob adjustment is simple to operate and no complex programming is required.

Energy conservation and status indication:

It has energy-saving functions when under light load, reducing energy consumption.

Equipped with LED indicator lights (green: operation, red: fault), it is convenient for status monitoring.

Bypass function: After the motor reaches its normal speed, the internal bypass contactor is connected, reducing power loss during operation and improving efficiency.

Application scenarios

Industrial Automation

It is used to control three-phase asynchronous motors, such as pumps, fans, compressors, conveyor belts, etc., to reduce starting shock and extend the service life of the equipment.

It is applicable to manufacturing production lines, packaging equipment and material handling systems.

Water treatment and pumping stations: The soft stop function effectively avoids the "water hammer effect" in the pump system, making it suitable for sewage treatment, water supply systems, and irrigation equipment.

HVAC system: Controls ventilation equipment, air conditioning compressors, etc., ensuring smooth start-up and reducing the impact on the power grid. It is suitable for commercial buildings and industrial facilities.

Food and beverage industry: Used in food processing equipment (such as mixers, conveyors), providing smooth start-up and reliable protection, meeting strict hygiene and safety requirements.

Traditional system upgrade: Replace the traditional star-delta starter or directly start the equipment to enhance system efficiency and reduce maintenance costs. It is suitable for the renovation of old factories.

Explosion-proof environment: Compliant with the ATEX directive, it is suitable for increased safety type (EEx e) explosion-proof motors and is widely used in hazardous environments such as petroleum and chemical industries.
